- Page 1 CE USER MANUAL Lacros Electric Folding Bicycles WWW.LACROS.NL ELECTRIC (FOLDING) BICYCLES FROM THE NETHERLANDS INTELLIGENT, RELIABLE AND COMFORTABLE WWW.LACROS.NL...
-
Page 2: For Your Safety
1. The LACROS electric bicycle is equipped with an electric motor. It is of great importance that you get used to the bike quickly. We advise you to choose quiet roads for your first "cycle practices" with little traffic situations and a pleasant road surface. -
Page 3: Quality Standard
CE User Manual LACROS 1.9 EN Quality standard Your product concerns an electric folding bicycle. The A-weighted emission sound pressure level at the driver's ears is less than 70 dB(A). The bike can be folded at one or two locations, at the handlebar stem and/or at the middle of the frame. -
Page 4: Table Of Contents
Environment ............40 Unfolding the bicycle ..........20 Technical specifications ..........41 Folding the bicycle ............. 21 Scamper S200/S400 (XL) ........41 The Battery ..............22 Scamper S600 (XL) with Bafang mid-drive motor 41 Trotter ............... 23 Scamper S600 (XL) w. Motinova mid-drive motor 42 Ambling A200/A400 (XL) ........ -
Page 5: The Saddle And Handlebar Height
CE User Manual LACROS 1.9 EN The saddle and handlebar height Figure 1: seat or handlebar post Figure 2: seat or handlebar post It is possible to adjust the saddle and handlebar height by loosening the clamp in figure 2. Subsequently, you can move the seat or handlebar up or down. -
Page 6: The Brakes
CE User Manual LACROS 1.9 EN The tires are equipped with a Dutch valve (Blitz) or a car valve (Schräder). A tire with a Dutch valve can be inflated with a standard bicycle pump. An adapter nipple also fits on these valves so that you can inflate the tire with a car tire pump. -
Page 7: Gears
CE User Manual LACROS 1.9 EN Gears Derailleur Note: you should keep pedaling when switching gears. In addition, not much force should be put onto the pedals while shifting to keep the derailleur in good condition. Type 1 The shift mechanism of the derailleur is located on the right side of the steering wheel. -
Page 8: Control System Front And Rear Hub Motor
CE User Manual LACROS 1.9 EN Control system front and rear hub motor SM100 Display Turn on the display Press the "S" or " " button (A) on the left side of the display to switch on the bicycle's electrical circuit. Note that the battery should already be powered on. -
Page 9: Bs200 Display
CE User Manual LACROS 1.9 EN Additional display options By pressing the ''S'' or " " button sequentially, you can browse through various information at the bottom of the display: (A) Battery voltage (BATTERY) (B) Total km/miles (ODO) (C) Trip reading (TRIP) - Page 10 CE User Manual LACROS 1.9 EN Thumb lever walking position By pushing the thumb lever (A) down at a standstill, you activate the walking assist, giving support up to 6 km per hour. (Note: the walking assist via the thumb lever does not work when the bicycle is in support level "0".)
-
Page 11: C500B Display
CE User Manual LACROS 1.9 EN C500B Display Turn on the display Press the " " button (A) on the left side of the display to turn on the bicycle's electrical circuit. Note that the battery should already be powered on. A menu appears on the display; the electrical circuit is switched on. -
Page 12: The Operation Of The Electrical Support
CE User Manual LACROS 1.9 EN Additional display options By pressing the ''SET'' button sequentially, you can browse through various information at the bottom of the display: total km/miles mode (ODO), trip reading (TRIP), and cycling time (TIME). Reset trip reading Press and hold the "SET"... -
Page 13: Mid-Drive Motor Control System
CE User Manual LACROS 1.9 EN Mid-drive motor control system Bafang mid-drive motor Control Panel The display's control panel is located on the left side of the steering wheel. Press and hold the " " button (A) for a few seconds to turn on the display. - Page 14 CE User Manual LACROS 1.9 EN Additional display options By pressing the information button (A) sequentially, the display is browsed for various information: TOTAL = Total mileage TRIP = Trip reading RANGE = Range in selected support mode = Maximum speed...
-
Page 15: Motinova Mid-Drive Motor
CE User Manual LACROS 1.9 EN Motinova mid-drive motor Control panel (A) On/off button display (B) Increase support (keep pressed two seconds for automatic switching between support modes) (C) Decrease support (D) Walking assist (E) Settings (F) Lighting Display symbols... - Page 16 CE User Manual LACROS 1.9 EN Speed unit There are two possible settings for the speed unit, km/h or mile/h. If the setting changes, the values are automatically adjusted. You can adjust the speed unit in the following way (the bicycle must be stationary): 1.
-
Page 17: Scamper, Ambling, And Sketch Nestor
CE User Manual LACROS 1.9 EN Scamper, Ambling, and Sketch Nestor Unfolding the bicycle Magnetic frame lock (Scamper and Ambling) Push the wheels away from each other to unlock the magnetic frame lock. (A) Metal locking plate (B) Magnet (C) Locking direction... -
Page 18: Folding The Bicycle
CE User Manual LACROS 1.9 EN Folding the bicycle Folding the pedals Fold the pedals by pushing the entire pedal toward the bicycle and then folding it. Note: position the pedals so they cannot damage the frame when the bicycle is folded. -
Page 19: The Battery
The Battery Turning on the battery and reading the battery indication The battery of these Lacros bicycles is located in the luggage carrier. Turn on the electrical system using the button on the left side of the battery (B). Please note you have only activated the battery, and the display is still switched off. -
Page 20: Canter
CE User Manual LACROS 1.9 EN Canter Unfolding the bicycle Magnetic frame lock Push the wheels away from each other to unlock the magnetic frame lock. (A) Metal locking plate (B) Magnet (C) Locking direction (D) Locked position Unfolding the frame Spread the front and back parts of the frame until the frame is straight and the hinge is closed. -
Page 21: Folding The Bicycle
CE User Manual LACROS 1.9 EN Folding the bicycle Folding the pedals Fold the pedals by pushing the entire pedal toward the bicycle and then folding it. Note: position the pedals so they cannot damage the frame when the bicycle is folded. -
Page 22: The Battery
The Battery Turning on the battery The battery of the Lacros Canter is located in the frame. Turn on the electrical system using the button on the top side of the battery (B). Please note you have only activated the battery, and the display is still switched off. -
Page 23: Trotter
CE User Manual LACROS 1.9 EN Trotter Unfolding the bicycle Magnetic frame lock Push the wheels away from each other to unlock the magnetic frame lock. (A) Metal locking plate (B) Magnet (C) Locking direction (D) Locked position Unfolding the frame Spread the front and back parts of the frame until the frame is straight and the hinge is closed. -
Page 24: Folding The Bicycle
CE User Manual LACROS 1.9 EN Folding the bicycle Folding the pedals Fold the pedals by pushing the entire pedal toward the bicycle and then folding it. Note: position the pedals so they cannot damage the frame when the bicycle is folded. -
Page 25: The Battery
The Battery Turning on the battery The battery of the Lacros Trotter is located inside the frame. Turn on the electrical system using the key on the left side of the bicycle. Please note you have only activated the battery, and the display is still switched off. -
Page 26: Mustang
CE User Manual LACROS 1.9 EN Mustang Unfolding the bicycle Unfolding the frame Spread the front and back parts of the frame until the frame is straight, and the hinge is closed. Securing the frame clamp Secure the frame clamp (A +B) by pushing it against the frame. -
Page 27: Folding The Bicycle
CE User Manual LACROS 1.9 EN Folding the bicycle Folding the pedals Fold the pedals by pushing the entire pedal toward the bicycle and then folding it. Note: position the pedals so they cannot damage the frame when the bicycle is folded. -
Page 28: The Battery
The Battery Turning on the battery and reading the battery indication The battery of the Lacros Mustang is located behind the saddle. Turn on the electrical system by turning the key (A) to the right. Please note you have only activated the battery, and the display is still switched off. -
Page 29: Gemini
CE User Manual LACROS 1.9 EN Gemini Unfolding the bicycle Unfolding the frame Spread the front and back parts of the frame until the frame is straight, and the hinge is closed. Securing the frame clamp Secure the frame clamp (A +B) by pushing it against the frame. -
Page 30: Folding The Bicycle
CE User Manual LACROS 1.9 EN Folding the bicycle Folding the pedals Fold the pedals by pushing the entire pedal toward the bicycle and then folding it. Note: position the pedals so they cannot damage the frame when the bicycle is folded. -
Page 31: The Battery
CE User Manual LACROS 1.9 EN The Battery How to charge the battery The battery has one charging point (A), located on the right side of the Gemini G200/G400 models and on the left side of the Gemini Action models. Connecting the charger to the battery is recommended before plugging the 220V plug into the socket. -
Page 32: Sierra
CE User Manual LACROS 1.9 EN Sierra Turning the handlebar The handlebar can be turned by loosening the clamp and pushing the pin upwards. Unfolding the bicycle Unfolding the frame Spread the front and back parts of the frame until the frame is straight and the hinge is closed. -
Page 33: The Battery
The Battery Removing the battery The battery of the Lacros Sierra is located behind the saddle. The battery can be removed from the bicycle by first turning the key to the battery tray lock. Now gently pull the battery backward. -
Page 34: Papillon
CE User Manual LACROS 1.9 EN Papillon Unfolding the bicycle Unfolding and securing the handlebar Fold the steering column upwards (A) and secure it with the handlebar clamp (B). Unfolding the frame Stand on the left of the bicycle and hold the bike at the handlebars and the curved bar in the middle. -
Page 35: The Battery
(C). The Battery How to charge the battery The battery of the Lacros Papillon is located inside the frame. battery has one charging point (A) left behind the front lamp. Connecting the charger to the battery is recommended before plugging the 220V plug into the socket. -
Page 36: Range
Charging advice • Always charge the battery with the Lacros charger supplied with the bicycle. Do not use a different charger. • The first two charges of a new battery should be more than 60%. To achieve this, wait the first two times to charge until the battery charge indicator on the display has dropped below 40%. -
Page 37: Warnings
• Never disassemble the bicycle yourself. If a part replacement is necessary, please get in touch with your Lacros dealer or Shinga B.V. for the relevant part. We always recommend using original parts. • Do not lend your bicycle to people with little experience with an electric bike. -
Page 38: Warning Symbols
Contact your Lacros dealer or Shinga B.V. directly to have the damaged parts replaced. • Rims are subject to wear and tear. Have your rim checked by your Lacros dealer or Shinga B.V. if it shows damage, pay specific attention to (small) cracks. •... -
Page 39: Warnings
CE User Manual LACROS 1.9 EN Attention. Turning these 2 screws is prohibited. It will lower lever sensitivity WARNING This bicycle is not designed for competition, Booster sensor = Magnetic rotation sensor stunting, jumping, or off-road use. Bicycling can be hazardous. -
Page 40: Maintenance
Following the environmental regulations for the intake and processing of batteries of the Dutch Ministry of VROM, we advise you always to return the battery to your Lacros dealer or Shinga B.V. They are obliged to collect the battery and take care of the further processing of the battery. -
Page 41: Technical Specifications
CE User Manual LACROS 1.9 EN Technical specifications Scamper S200/S400 (XL) • Dimensions unfolded (L x W x H): 160x60x113cm (20") 173x60x128cm (24") • Dimensions folded (L x W x H): 90x40x72cm (20") 90x40x80cm (24") • Frame: Aluminum • Motor type: Rear hub motor •... -
Page 42: Scamper S600 (Xl) W. Motinova Mid-Drive Motor
CE User Manual LACROS 1.9 EN Scamper S600 (XL) with Motinova mid-drive motor • Dimensions unfolded (L x W x H): 160x63x115cm (20") 173x63x130cm (24") • Dimensions folded (L x W x H): 90x40x72cm (20") 90x40x80cm (24") • Frame: Aluminum •... -
Page 43: Canter C200
CE User Manual LACROS 1.9 EN Sketch Nestor • Dimensions unfolded (L x W x H): 176x62x119cm • Dimensions folded (L x W x H): 176x22x78cm • Frame: Aluminum • Motor type: CS500 Motinova mid-drive motor • Motor voltage: •... -
Page 44: Trotter T200/T400 (Xl)
CE User Manual LACROS 1.9 EN Trotter T200/T400 (XL) • Dimensions unfolded (L x W x H): 160x60x113cm (20") 165x60x108cm (24") • Dimensions folded (L x W x H): 90x40x69cm (20") 100x40x78cm (24") • Frame: Aluminum • Motor type: Rear hub motor •... -
Page 45: Sierra
CE User Manual LACROS 1.9 EN Gemini G200/G400 (Action) • Dimensions unfolded (L x W x H): 135x62x100cm • Dimensions folded (L x W x H): 80x40x58cm • Frame: Magnesium (G200/G400) PVC (G400 Action) • Motor type: Rear hub motor •... -
Page 46: Papillon
CE User Manual LACROS 1.9 EN Papillon • Dimensions unfolded (L x W x H): 128x63x109cm • Dimensions folded (L x W x H): 93x25x71cm • Frame: Aluminum • Motor type: Front hub motor • Motor voltage: • Motor power: 180W •... -
Page 47: Ec Declaration
NETHERLANDS NETHERLANDS Product: Electric folding bicycle Model: LACROS Scamper S200(XL)/S400(XL)/S600(XL), Ambling A200(XL)/A400(XL), Sketch Nestor, Canter C200, Trotter T200, T400(XL), Mustang M250, Gemini G200/G400(Action), Sierra, Papillon THIS ELECTRIC BICYCLE IS PRODUCED ACCORDING TO AND IN APPLIANCE WITH THE DIRECTIVES OF THE EUROPEAN UNION ON ELECTRIC BICYCLES WITH A MAXIMUM SPEED <... - Page 48 CE User Manual LACROS 1.9 EN LIFE IS LIKE RIDING A BICYCLE. TO KEEP YOUR BALANCE, YOU MUST KEEP MOVING. - ALBERT EINSTEIN WWW.LACROS.NL...
