Hardware layout and configuration

5 Hardware layout and configuration
Figure 2
board and the modem expansion board. The connection is done through the STMod+
connector.
5.1

Board layouts

There is no LCD with the STM32L496AGI6-based Discovery main board in this pack. For
the main board detailed description, refer to the user manual Discovery kit with
STM32L496AG (UM2160) at www.st.com.
SMA antenna
LTE IoT modem
Red LED for modem
10/22
illustrates the connection between the STM32L496AGI6-based Discovery main

Figure 2. Main board and expansion LTE IoT modem top view

ready
UM2365 Rev 3
UM2365
Micro USB type AB for
firmware update
Embedded SIM
Green LED for modem
signaling mode
STMod+ connector
STLINK USB
Main USB
MSv49532V2
