B. The New Commands
Command
~Q±n
~X5
~X6
BA2,x,y,narrow,wide,height,rtation,readable,data
BN2,x,y,narrow,wide,height,rtation,readable,data
BQ2,x,y,narrow,wide,height,rotation,readable,data
AZn, x, y, x_mul, y_mul, gap, rotation, data
n=Asia font type, from 1 to 4.
rotation : from 4 to 7, Asian font only
4) 0 5) 90 6) 180
^Yp1,p2,p3,p4
p1: Baud rate (48=4800, 96=9600, 19=19200, 38=38400)
p2: Parity (N=None, O=Odd, E=Even)
p3: Number of data bits (7, 8)
p4: Number of stop bits (1, 2)
^Mx
x = forward length (mm)
^Bx
x = backward length (mm)
Hx,y,row,colmn,row_width,col_width,line_width
x : left-upper Hori .pos. (dots)
y : left-upper Vert. Pos. (dots)
row : numbe of rows
column : number of columns
row_width : row width
col_width : column width
line_width : line width
~MDELx,name
x: type (G: Graphic; F: Label; E: Font)
name: the name of the graphic, label or font
7) 270
22
Description
Row Offset Adjustment
Print out the Asia fonts in printer
Feed back the total printed length through
the printer's Serial port
CODE39 with check digit
I 2/5 with check digit
CODE128 A or B or C
Print the Asian character strings oriented
from left to right (rotation values from 0 to 3)
or top to bottom (rotation values 4~7)
The Asia font is downloadable. To download
the Asia font, refer the folder
\fontload\readme.txt in the CD.
Setting the RS232
Forward
Backward
Table
Clear the Font, Graphic, Label
