0) 0 1) 90
data : Data string (up to 239 characters).
1. Constant
2. Date information (^D)
3. Time information (^T)
4. Serial variable (^Cx)
5. Variable data (^Vxx)
Prints an ASCII or ASIA text string (refer page15). The ASCII text oriented form left to right,
Description :
the Asian text from left to right or top to bottom.
11. Barcode
Syntax : Bt,x,y,narrow,wide,height,rotation,readable,data
Parameter : t : bar-code type
A
A2
B
C
D
E
F
G
H
I
J
K
x : Hori. of left-bottom pos. of barcode (unit: dot, 1 mm = 8 dots)
y : Vert. Of left -bottom pos. of barcode (unit: dot, 1 mm = 8 dots)
narrow (x dimension): narrow bar from 1 ~ 10 dots (0.125 ~ 1.25 mm)
** DUN 14 narrow setting from 5 ~ 8 dots; UPC/EAN narrow setting from 2 ~ 4 dots **
wide : wide bar from 2 ~ 30 dots (0.25 ~ 0.5 mm) ; **CODE 39, 93, CODABAR & I 2 of 5**
height : height of barcode from 24 ~ 1200 dots.
rotation : rotation of barcode (0 ~ 3)
0) 0 1) 90
readable : 0- label off, 1- label on
data : bar-code data:
1. C onstant
2. Date information (^D)
3. Time information (^T)
4. Serial variable (^Cx)
5. Variable data (^Vxx)
Description : Used to print standard barcodes (refer page15)
12. PDF 417
Syntax : Px,y,w,h,r,c,ec,len
Data
Parameters : x : Hori. of left-bottom pos. of barcode ( unit : dots)
y : Vert. of left-bottom pos. of barcode (unit : dots)
w : Width (x dimension) of the narrowest element (bar or space) in the barcode.
h : Height (y dimension) of each barcode row in the symbol.
r : number of barcode rows, from 3 to 90. If you key in 0, printer will count all the rows.
c : number of barcode columns, from 1 ~ 30. If you key in 0, printer will count the all columns.
ec : error correct ion level: 0 ~ 8.
len :number of encoded data bytes, including carriage returns
Data : data to be encoded(the length of the data is equal to len; up to 1024 characters)
Description : Print a 2 dimensional PDF417 code (refer page16)
13. Maxicode
Syntax : Mx, y, sno, nos, mode, ccode, zip, class, rotation, message
Parameter : x : Hori. of left-bottom pos. of barcode (unit: dots).
y : Vert. of left-bottom pos. of barcode (unit: dots).
sno : symbol number, in set of symbols: 1 ~ 8.
nos : number of symbols in set of symbols: 1 ~ 8 sets.
2) 180 3) 270
Code 39
Code 39 with check digit
EAN 8
EAN 8 - Add ON 2
EAN 8 - Add ON 5
EAN 13
EAN 13 – Add ON 2
EAN 13 – Add ON 5
UPC A
UPC A - Add ON 2
UPC A - Add ON 5
UPC E
2) 180 3) 270
4) 0 5) 90 6) 180
L UPC E - Add ON 2
M UPC E - Add ON 5
N I 2 of 5
N2 I 2 of 5 with check digit
O Codabar
P Code 93
Q Code 128 (auto subset A/B/C)
Q2 Code 128 (subset A/B/C)
R UCC 128
S Post NET
T DUN 14 ONLY 90
U EAN 128
V RPS 128
and line feed.
11
7) 270
