Godex EZ-4TKP Programing Manual page 16

1. Text
Example
^Q50,0,2
^W50
^S3
^H10
^R10
~D8,27,00,8,39,36
^L
AC,10,10,1,1,1,0,PRINTER
AC,10,50,1,1,1,0,^D
AC,10,100,1,1,1,0,^T
E
Adjusting the character
spacing
^Q30,0,0
^W50
^S3
^H10
^L
AC,10,10,1,1,10,0,PRINTER
AC,10,100,1,1,1,0,PRINTER
E
The data output is a default setting and user can change it with ~D command (refer page9).
? ?
The time output format is a default setting and user can change it with T command.
? ?
2. Barcode
^H10
^S3
^Q30,0,2
^W60
^L
BB,20,100,3,3,100,0,1,1234567
E
3. RTC Setting
Change the date formatting
Dy4-me-dd
Dy4/mn/dd
Dmn|dd|y4
Dy4
Dme
Ddd
Dy4,me
Dme-dd
4. Line printing
Example
^Q50,3
^W100
^E32
^H7
^P1
^S3
^L
LO,212,45,311,53
LO,244,11,252,128
LE,34,43,149,51
LE,72,8,80,121
E
Result
PRINTER ^Q50,0,0
AUG/27/00 ^W50
08:39:36 ^S3
^H10
^L
AC,100,30,1,1,1,0,ROTATION 0
AC,40,20,1,1,1,1,ROTATION 90
AC,260,150,1,1,1,2,ROTATION 180
AC,290,200,1,1,1,3,ROTATION 270
E
Result
P R I N T E R
^L
AZ,100,12,1,1,0,4,? ?
AZ,220,50,1,1,0,5,? ?
AZ,75,83,1,1,0,6,? ?
PRINTER
AZ,121,144,1,1,0,7,? ?
E
Result
2000-MAY-29
2000/05/29
05|29|2000
2000
MAY
09
2000-MAY
MAY-29
Description
; Darkness= 6
; Speed = 2 inch/second
; Label height = 50mm, gap = 2 mm
; Label width = 60mm
; (x,y)=(10,10), (x1,y1)=(60,200)
; (x,y)=(100,10), (x1,y1)=(400,200)
15
Rotate printing
Asia Font
Rotation of barcode
^H10
^S3
^W25
^Q30,0,2
^L
BE,100,20,2,4,80,1,1,123456789012
E
Result
Result
ROTATION 0
180 ROTATION
Result
Result
Result
