wwcomplements
Section:
HEIGHT ADJUSTABLE BENCH
Description:
WWCOMP HA BENCH - AP & EU
Single-Sided Rectangular Worksurface (MHWBWBS/EHWBWBS), Single
-Sided Rectangular Worksurface w/ Radius Corners (MHWBWJS/EHWBWJS)
Single-Sided Frame(MHWBFYS/EHWBFYS) Extension Block(EHWBFWK)
NOTE:Installation for
WWComplements Europe (EU)
is same as Asia Pacific (AP).
Installation Guides
A2
A3
D1 or D2
E
NOTE:For WWComplements
Europe (EU) products starts
with EH and for Asia Pacific
(AP) starts with MH.
A1
B1
C1
Date:
WWC_101
Part and Product Identification
A1 - Rectangula HA Wksf. for-
A1 - Rectangular HA Wksf.
hiSpace(C07-7610) x1 (for
OR
for- hiSpace W\ Rad. (C07-7611) x1
MHWBWBS/EHWBWBS)
(for MHWBWJS/EHWBWJS)
A3 - Rect. Grommet
A2 - Access Door Asm.
(RAGC) x1(for both)
(N01-4759) x1 (for both)
B1 - Telescope Frame (N01-4851)x1
B2 - Motor Housing
Cover (A16-9446) x2
B4 - Cam Handle w/
Cotter Pin. (N09-9814) x2
C1 - Frame Connecting
Tube Kit (X01-4012) x1
D1 -Leg L/R
(N01-4876) x2
OR
(N01-4852) x2
D2 -Fixed Height
Leg L/R (N01-7476) x2
D5 - Right Angle
D7 - 3m Power
D6 - 3m Power
Connector 1m Lg.
Cord (I04H-0007) x1
Cord (D06-4293)x1
(D06-4277) x2
D9 - Keypad,
D10 - #10 x 25mm, zinc
D11 - #4 x 25mm, zinc
hiSpace Table
(E01-1415) x2
(E01-1470) x4
(D06-4276) x1
YS Feet (Pair),
E1 -
E2 -
M6X14 -
Hispace Table
SHCS
(N09-5784) x1
(E04-0096)
F3 - M6 x 16mm
F2 - Base Link
F1 - Base Link, SS
Screw Chrome
Cover, SS
(A16-8545) x1
(E01-1409) x4
(A16-8546) x1
Oct 2022
Page No:
1 of 20
Rev. No: 0
A4 - M5x0.8 Pan Head
Machine Screw
E01-1106)x10
B3 - Wood Screw
#10x20mm
(E01-1414) x16
C2 - M8x25mm Flat Socket
Head Screw (E01-1410) x4
D4 -
ControlBox
D3
W\Anti Collison
-CableClamp
(D06-4275\650)x1
OR
(B02-0558)x10
(D06-4275\663)x1
D8 - Toggle
Switch Kit
(N01-7336) x1
D12 - #6 x 20mm
(E01-1417) x10
E3 -
Leveler
(D06-4291)
x4
x8
G -
Extension
block(A25-0776)
x4or32
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Teknion WWComplements WWCOMP HA
Summary of Contents for Teknion WWComplements WWCOMP HA
- Page 1 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 1 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 Rev. No: 0 Part and Product Identification Single-Sided Rectangular Worksurface (MHWBWBS/EHWBWBS), Single -Sided Rectangular Worksurface w/ Radius Corners (MHWBWJS/EHWBWJS) Single-Sided Frame(MHWBFYS/EHWBFYS) Extension Block(EHWBFWK) A1 - Rectangula HA Wksf.
- Page 2 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 2 of 13 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH TELESCOPE FRAME TO WORKSURFACE SECURE TELESCOPE FRAME NOTE: Loosen the Set Screws on the Telescopic Frame and Shorten or Lengthen the Frame to align the Pilot holes on the Frames and Worksurfaces.
- Page 3 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 3 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 SECURE TELESCOPIC FRAME - 2 STEP 3: Attach the rest of the screws to completely secure Telescopic Frame as shown. In Europe Worsurface Machine screws are used to fasten the frame as shown...
- Page 4 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 4 of 13 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH MOTOR HOUSING COVER STEP 4: Attach Motor Housing Cover to the Telescopic Frame and secure it by snapping it.
- Page 5 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 5 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH LEGS TO TELESCOPIC FRAME SECURE LEGS TO WORKSURFACE NOTE: Attach D1- LEG (N01-4876) for EHWBFYS (Europe version) or attach D1- LEG (N01-4852) for MHWBFYS (Asia-Pacific version) NOTE: D1 Leg (N01-7543) is for...
- Page 6 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 6 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH LEGS TO TELESCOPIC FRAME SECURE LEGS TO WORKSURFACE NOTE: Brackets will face away from User towards back of worksurface NOTE: D2 Leg (N01-7764) is for FIxed bench (EHWBFYS) STEP 5B: Attach Legs to Telescopic Frame as shown.
- Page 7 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 7 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 INSTALL CAM HANDLE SECURE CAM HANDLE STEP 7: Install Cam Handle as shown. and make sure it is locked in. STEP 8: Insert pin and lock Cam Handle as shown.
- Page 8 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 8 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH FRAME CONNECTING TUBE SECURE FRAME CONNECTING TUBE STEP 9: Attach the Frame Connecting Tube assembly to the Brackets on the Leg Assembly. STEP 10: Secure the Frame Connecting Tube Assembly using the Screws provided.
- Page 9 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 9 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH FEET TO LEGS NOTE: Feet Installation for NOTE: Feet Installation for 08 depth configuration 07 depth configuration STEP 11: Attach Feet to Legs with provided screws.
- Page 10 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 10 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH AND SECURE CONTROL BOX NOTE: Attach D4-Control Box(D06-4725\650) for EHWBFYS (Europe version) or attach D4-Control Box(D06-4725\663) for MHWBFYS (Asia-Pacific version) STEP 12: Attach Control Box to worksurface using Screws provided.
- Page 11 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 11 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH CONNECTOR TO CONTROL BOX STEP 13: Attach the Connector Cable to Control box and to Leg as shown. Arrange the extra wire between the Telescopic Frame.
- Page 12 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 12 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH SWITCH AND WIRE MANAGEMENT Anti-Collision Dongle NOTE: Make Sure the Anti- Collision NOTE: Don't have to Attach Dongle is attached to the Control Box.
- Page 13 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 13 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH SWITCH AND WIRE MANAGEMENT NOTE: Don't have to Attach Toggle switch for fixed height (EHWBFYS2F) NOTE: Attach D6- 3m Power Cord (D06-4293) for EHWBFYS (Europe version) or attach D7-3m Power Cord...
- Page 14 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 14 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 PLACE CABLE CLAMP NOTE: Attach D6- 3m Power Cord (D06-4293) for EHWBFYS (Europe version) or attach D7-3m Power Cord (I04H-0007) for MHWBFYS (Asia-Pacific version) STEP 15: Place Cable Clamps as shown.
- Page 15 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 15 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 TURN THE TABLE ASSEMBLY NOTE: Please Make sure to have at least Two Persons for this Step. STEP 16: Turn the Table Assembly.
- Page 16 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 16 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ROUGH LEVELING NOTE: If the difference in elevation is >10mm use Single-Sided Leveler Extension Blocks (SOLD SEPARATELY) to increase leveling range.
- Page 17 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 17 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH BASE LINK ATTACH BASE LINK COVER STEP 18: Attach Base Link to underside of Frame Connecting Tubes and secure using STEP 19: Attach the Base Link Cover to the Base Link by placing it on the bracket and provided screws.
- Page 18 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 18 of 20 Description: WWCOMP HA BENCH - AP & EU WWC_101 LEVELING BENCH - FINAL ADJUSTMENTS NOTE: It is recommended to use a laser level tool to check final alignment.
- Page 19 WWComplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH Date: Oct 2022 Page No: 19 of 20 Description: WWCOMP HA BENCH- AP & EU WWC_101 ALIGN LEVELER EXTENSION BLOCKS, EU 3/ 8" NOTE: The feet on Single Sided Benches allow 3/ 8" leveleing NOTE: Extension blocks are used if we couldn't level the table by adjusting the leveler.
- Page 20 wwcomplements Installation Guides Section: HEIGHT ADJUSTABLE BENCH 20 of 20 Date: Oct 2022 Page No: Description: WWCOMP HA BENCH - AP & EU WWC_101 ATTACH GROMMET AND ACCESS DOOR ASSM SECURE ACCESS DOOR ASSEMBLY Wood Screw STEP 22: Attach Grommet and Access Door Assembly to the Worksurface. STEP 23: Secure Access Door Assembly to the Worksurface using 2 Wood Screws and Fasten it through the Pilot Hole shown.
