3-5. Parallel/PS2 Adapter Installation
1
Parallel Cable
2
Parallel/PS2 Adapter
3
Connector Cable
4
Screw x 2pcs
1.
Make sure the power is off
and the power cable is
unplugged. Place the
printer onto a smooth
surface and open the top
cover.
2.
Unscrew two screws as
indicated in figure and
remove the left top cover
from the printer.
3.
Unscrew the screws of
parallel port cover and
remove the cover.
EZ-2000+/6000+ User's Manual Rev. D
1
3
34
