ECLYPSE Web Interface

BLE Room Devices

The BLE Room Devices tab enables web configuration of the ECY-STAT's Bluetooth
technology enabled features. The Bluetooth features must first be correctly programmed into the con-
troller using EC- gfx Program before they will appear in this tab.
BLE Room Devices
The BLE Room Devices main screen presents the details of the Bluetooth enabled room device cur-
rently programmed in your ECLYPSE controller.
Figure 67: BLE Room Devices Web Page
Item Description
Subnet ID This indicates the current subnet ID assigned to the device.
Model Type This indicates the model of the BLE enabled device.
Enter a description of the room or location of where the device is located. This name will appear on the
Room Name
ECY-STAT screen as well as in the my PERSONIFY mobile application device list.
Choose the Bluetooth mode required for the device.
-Disabled: Bluetooth connection is disabled and does not allow any wireless connections to the device.
-Open: Bluetooth connection is open and is not authenticated with a PIN code. We recommend this option
for rooms or areas that are accessible to anyone.
Bluetooth Mode
-Private: Bluetooth connection is authenticated with a six (6) digit PIN code.
the six-digit pin code can only be found on the ECY-STAT itself from the my Personify App tab and
tapping Show code.
See the
Use the
Space Owners
information.
Define display names and enable or disable the sunblind groups. Sunblind groups must first be added
Sunblind Groups
and configured in EC- gfx Program. See the EC- gfx Program User Guide for more information.
Define display names and enable or disable the light groups. Light groups must first be added and
Light Groups
configured in EC- gfx Program. See the EC- gfx Program User Guide for more information.
Define display names and enable or disable Custom Actions. Custom Actions must first be added and
Custom Actions
configured in EC- gfx Program. See the EC- gfx Program User Guide for more information.
Click to refresh the information in the list.
90
my PERSONIFY App chapter for more information.
icon to add, edit, delete, and assign users as a space owner. See
When this mode is selected,
ECLYPSE Connected Thermostat (ECY-STAT)
low energy
®
Space Owners for more
