HVAC Mode

The main HVAC controls can be found here. The center graphic displays the current HVAC mode set-
ting.
Icon
ECLYPSE Connected Thermostat (ECY-STAT)
Navigating the User Interface
Description
The Eco icon toggles Eco mode ON. To turn Eco mode OFF,
toggle another HVAC mode ON. The HVAC mode parameters
are configured using EC- gfx Program. See the EC-gfxProgram
User Guide for more information.
The Heat icon toggles Heating mode ON. To turn Heating
mode OFF, toggle another HVAC mode ON. The HVAC mode
parameters are configured using EC- gfx Program. See the EC-
gfxProgram User Guide for more information.
The Cool icon toggles Cooling mode ON. To turn Cooling
mode OFF, toggle another HVAC mode ON. The HVAC mode
parameters are configured using EC- gfx Program. See the EC-
gfxProgram User Guide for more information.
The power button icon turns the HVAC mode OFF. To turn the
HVAC mode ON, toggle another HVAC mode ON. The HVAC
mode parameters are configured using EC- gfx Program. See
the EC-gfxProgram User Guide for more information.
The A icon turns Auto mode ON. To turn Auto mode OFF,
toggle another HVAC mode ON. The HVAC mode parameters
are configured using EC- gfx Program. See the EC-gfxProgram
User Guide for more information.
