Temperature Control

The main temperature settings can be adjusted here. Ambient temperature is displayed in the middle
of the screen.
Depending on the programming with EC- gfx Program, temperature will be displayed in either Absolute
or Relative mode. Shown below is Absolute mode.
Icon Description
Tap and hold the slider icon to adjust the temperature setpoint. Alternatively, you can tap a position on the
slider to jump to that position.
The percent humidity is indicated here.
The temperature setpoint and heating/cooling mode is displayed here. Depending on the chosen
programming, the setpoint offset may be displayed instead.
The ambient temperature is displayed here.
Auto OFF / ON
The Auto icon toggles automatic mode ON. To turn Auto mode OFF, adjust the temperature setpoint
slider. The auto function parameters are configured using EC- gfx Program. See the EC-gfxProgram User
Guide for more information.
ECLYPSE Connected Thermostat (ECY-STAT)
Navigating the User Interface
115
