Silver Mobile Dual TV Cart
Instruction Manual
SKU: STAND-TV12H
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv12h
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV12H
Summary of Contents for Vivo STAND-TV12H
- Page 1 Silver Mobile Dual TV Cart Instruction Manual SKU: STAND-TV12H Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv12h GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 DO NOT EXCEED WEIGHT CAPACITY. TOOLS NEEDED 11lbs 110lbs Failure to do so may result in serious injury. (5kg) (50kg) DVD SHELF PER SCREEN Phillips 11lbs Screwdriver (5kg) CAMERA SHELF ASSEMBLY STEPS STEP 1 Screw Casters (B) into underside of Base (A). Adjust Casters (B) to sit flat on surface if needed, and tighten nuts using wrench (T-B) as shown.
- Page 4 STEP 2 (Continued) Place the Columns (E, F) into the cutouts in the Base (A). Slide the Plastic Handles (D) over the inner columns and press firmly in place. NOTE: Lock the casters in place to prevent movement during assembly. Secure columns using M8x25mm Screws (S-H) and tighten with Allen Wrench (T-A).
- Page 5 STEP 3 (Continued) Attach the DVD Shelf (K) to the Support Bar (O) with M6x14mm Screws (S-G), M6x25mm Screw (S-B) and Knobs (P). Attach the Support Bar (O) with DVD shelf (K) to the support blocks on columns with M6x25mm (S-B) and Allen Wrench (T-A).
- Page 6 STEP 5 Hang TV onto the Universal Plate (C). Turn the bolts on the underside of the brackets counter- clockwise to lock. Turn the bolts clockwise to unlock and remove the displays. Padlocks (not included) can be used to prevent the displays from being stolen. STEP 6 Manage cables using the cable grommets in the columns.
- Page 7 STEP 7 Attach the Camera Shelf (M) to the Connecting Plate (L) using M4x6mm Flathead Screws (S-D) on top and M4x6mm Dome Head Screws (S-E) in back. STEP 8 Attach the Connecting Plate (L) to the center holes in Fixing Plates (N) using M6x25mm Phillips Head Screws (S-B), M6 washers (S-K) and Spacers (S-J).
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
