White Mobile TV Cart
Instruction Manual
SKU: STAND-TV12H
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv12h
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV12H
Summary of Contents for Vivo STAND-TV12H
- Page 1 White Mobile TV Cart Instruction Manual SKU: STAND-TV12H Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv12h GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 DO NOT EXCEED WEIGHT CAPACITY. TOOLS NEEDED 110lbs 11lbs Failure to do so may result in serious injury. (50kg) (5kg) DVD SHELF PER SCREEN Phillips Screwdriver 11lbs (5kg) CAMERA SHELF ASSEMBLY STEPS STEP 1 Screw casters (B) into underside of base (A). Adjust casters (B) to sit flat on surface if needed, and tighten nuts using wrench (C1) as shown.
- Page 4 STEP 2 (Continued) Place the columns (E, F) into the cutouts in the base. Slide the plastic handles (D) over the inner columns and press firmly in place. NOTE: Lock the casters in place to prevent movement during assembly. Secure columns using M8x25 bolts (X) and tighten with Allen wrench (B1). Slide connectors (J) onto back of universal plates (C) as shown and secure with M6x15 bolts (Q).
- Page 5 STEP 3 (Continued) Attach the DVD shelf (K) to the support bar (O) with x2 M6x14 bolts (W), M6x25 carriage bolts (Y) and knobs (P). Attach the support bar (O) with DVD shelf (K) to the support blocks on columns with M6x25 bolts (V) and Allen wrench (B1).
- Page 6 STEP 5 Hang the adapter brackets (G, H) with displays onto the universal plate (C). Turn the bolts on the underside of the brackets counter-clockwise to lock. Turn the bolts clockwise to unlock and remove the displays. Padlocks (not included) can be used to prevent the displays from being stolen. STEP 6 Manage cables using the cable grommets in the columns.
- Page 7 STEP 7 Attach the camera shelf (M) to the connecting plate (L) using M4x6 flat head bolts (T) on top and M4x6 dome head bolts (U) in back. STEP 8 Attach the connecting plate (L) to the center holes in fixing plates (N) using M6x25 Phillips head bolts (R), D6 washers (A1) and spacers (Z).
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
