White Mobile Portrait to Landscape TV Cart
Instruction Manual
SKU: STAND-TV02PW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv02pw
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-TV02PW
Summary of Contents for Vivo STAND-TV02PW
- Page 1 White Mobile Portrait to Landscape TV Cart Instruction Manual SKU: STAND-TV02PW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv02pw GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
- Page 3 TOOLS NEEDED Phillips Wrench Needle Nose Screwdriver Pliers ASSEMBLY STEPS STEP 1 Press the lock on each Caster (B) to the down (locked) position, then install the Casters to the Base (A). Adjust to sit flat if needed, then tighten each caster using the 10mm Wrench (v). STEP 2 Slide the Base Poles (C) into the Base making sure the cable holes are facing...
- Page 4 STEP 4 Slide the Shelf Mounting Brackets up to cover the installed scrws, then insert M6x12mm Screws (S-C) to secure the brackets. Tighten with a Phillips screwdriver. STEP 5 1. Install Front Cover (G) between poles, making sure the face of the cover is facing towards the front, and secure using M6x12mm Screws (S-C).
- Page 5 STEP 6 (Continued) OPTION B: VESA 600x200mm - 600x400mm Attach VESA Extensions (J, K) to the Mounting Plate (H) using M8x8mm Screws (S-E), and tighten with the 5mm Allen Wrench (T-D). Install the assembled mounting plate to the TV. For flat back TVs, use shorter Screws (M-A, M-B) with M8 Washers (M-E).
- Page 6 STEP 8 Insert M8x20mm Screws (S-A) into either the front or rear lower holes of the mounting plate. Tighten all screws with the 5mm Allen Wrench (T-D). STEP 9 To adjust the ease of rotation, loosen or tighten the nuts on the back of the mounting plate using 6mm Wrench (T-A).
- Page 7 STEP 11 (Continued) Place a power strip in the back of the mounting plate, and secure using Cable Ties STEP 12 Install Cable Covers (L) to the cables holes in the poles, using pliers to break out sections for x2 or x3 cables if needed. STEP 13 Place the Rear Cover (I) onto the back of the mounting plate and secure using M6x8mm (S-B)
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
