Unpacking and verification of integrity

5
We recommend the equipment be unpacked after moving it to its installation location and only when
it is to be installed. This operation must be performed using personal protection equipment (i.e., gloves,
safety shoes, etc.).
Do not leave the packing unattended: it is potentially harmful to children and animals
(suffocation hazard).
Some packing materials must be kept for future use (wooden crates, pallets, etc.), while those that
cannot be reused (i.e., polystyrene, strapping, etc.) must be disposed of in compliance with the
regulations in force in the country of installation: this will protect the environment!

After unpacking

After unpacking, check the received contents:
Installation and operation manual (IOM)
•
Wiring diagram
•
Declaration of conformity
•
Check therefore that you have received all the components and that they are undamaged
In case of damaged or missing parts.
do not move, install or repair
•
take quality photos
•
Find the serial number plate
•
Immediately
• notify the carrier that delivered the unit;
promptly
• contact the Manufacturer (keep available the serial number of your unit).
Please note that complaints or claims of damage reported after 10 days of receipt of the unit can-
not be accepted
D
I
F
H
A
18
damaged components and the unit in general.
to document the damage.
on the unit and note the unit's serial number;
E
C
B
G
A: Manufacturer's name and data
DAIKIN APPLIED EUROPE S.P.A.
Via Piani di Santa Maria, 72 - 00072 Ariccia (Roma) - Italy
Tel: (+39) 06 93 73 11 - Fax: (+39) 06 93 74 014
B: CE markings
C: Unit weight
D: Code and POS
E: Date of manufacture
F: Supply air flow
G: Return air flow
H: Electrical specifications (frequency, number of phases,
absorption in plate conditions)
I: Unit serial number
