SIZE 6-7: electrical connections between sections
These 4 cables connect to the electrical panel board
12
(section B3)
J11- Supply fan signal
J13- Return fan signal
J16 - Recirculation damper
B
B
3
3
X11-
Return
temperature
X12- Outside
temperature
J13
PS1- Supply filter pressure switch
PS2- Return filter pressure switch
PS3 - Fan alarm
PS4 - Return alarm
B
B
2
2
Connection cables to the
electrical panel (for their
wiring, see the wiring diagram
supplied with the unit)
J11
PS1
These connections are
made within section B1
3 Pole connector
X11
X12
J16
J11 - Supply fan signal
J13 - Return fan signal
J16 - Recirculation damper
PS1 - Supply filter pressure switch
PS2 - Return filter pressure switch
PS3 - Fan alarm
PS4 - Return alarm
X11 - Recovery temperature
X12 - Outside temperature
PS3
PS4
12
SIZE 6-7: electrical connec-
PS2
tions between sections
SGN + AL
4 pole fan
B
B
1
1
fan supply
