PHASE 4: MECHANICAL UNION OF THE SECTIONS (SIZES 05-06-07)
Pass all the cables through the holes provided and then join the various sections as shown in the
9
figure. Size 5 has two sections, sizes 6 and 7 have three sections.
x4
x3
x1
x1
2
9
SIZES 05-06-07: coupling of sections
1b
(sizes 06-07 only)
1a
2
x1
x1
3
27
