Safety measurements

E
Height
Length
Width
Duct collar diameter
Operating space in front
of the unit
3
u.m.
A
mm 1450
B
mm 1580
mm -
B1
mm -
B2
mm -
B3
C
mm 550
D
mm 250
E
mm 850
>20 mm
SIZE
4 5
1450 1750
1650 2170
- 600
- 1570
- -
790 790
315 355
1100 1100
>20 mm
6 7
1700 1900
2620 2950
480 580
1430 1560
710 810
790 890
400 500
1100 1200
13
