DAIKIN
DAIKIN ROOM AIR CONDITIONER
OPERATION MANUAL
MODELS:
F/G/MTKM35UV16W
F/G/MTKM50UV16U
F/G/MTKM60UV16U
FTKT35UV16W
FTKT50UV16V
FTKT60UV16U
FTKN35UV16W
FTKN50UV16V
A/D/F/G/MTKL35UV16W
A/D/F/G/MTKL50UV16V
A/D/F/G/MTKL50UV16U
A/D/F/GTKL60UV16U
F/GTKL 71 UV16T
A/F/G/MTKM50UV16VA
F/GTKC48UV16W
F/GTKC48UV16WA
3P665364-1Z M21P075F
3P665364-1Z M21P075F
Advertisement
Table of Contents
Related Manuals for Daikin GTKC48UV16W
Summary of Contents for Daikin GTKC48UV16W
- Page 1 DAIKIN 3P665364-1Z M21P075F DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS: F/G/MTKM35UV16W F/G/MTKM50UV16U F/G/MTKM60UV16U FTKT35UV16W FTKT50UV16V FTKT60UV16U FTKN35UV16W FTKN50UV16V A/D/F/G/MTKL35UV16W A/D/F/G/MTKL50UV16V A/D/F/G/MTKL50UV16U A/D/F/GTKL60UV16U F/GTKL 71 UV16T A/F/G/MTKM50UV16VA 3P665364-1Z M21P075F F/GTKC48UV16W F/GTKC48UV16WA...
-
Page 2: Safety Precautions
Safety Precautions &. CAUTI O N--------- • Keep this manual where the user can easily find it. • Read the precautions in this manual carefully before operating the unit. • Do not use the air conditioner for purposes other than •... -
Page 3: Name Of Parts
Read before Operation Name of Parts ■ Indoor Unit 1. Front panel 2.Air inlet 3.Air filter 4.Accessory filter* 5. Streamer unit * 6. Model name plate 7. Indoor temperature sensor: • Detects the air temperature around the unit. a.Display 9.Air outlet 10. -
Page 4: Remote Controller
ARC484B33 GTKM35/50/60UV16W/U/U 9. ECONO button: FTKN35/50UV16WN ARC484B35 ARC484B32 A/F/MTKM50UV16VA • ECONO operation. GTKM50UV16VA ARC484B33 F/GTKC48UV16W ARC484B33 10.COANDA/STREAMER button: ARC484B67 F/GTKC48UV16WA • COANDA/STREAMER operation. 11. TIMER CANCEL button: • Cancels the timer setting. 12.ON TIMER button 13.OFF TIMER button 14. GOOD SLEEP/DISPLAY button 15. -
Page 5: Preparation Before Operation
Read before Operatio Preparation before Operation & CAUTION----------------- Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. - Page 6 t, � Operation ;\1i-t•X•l. 11-i j ;J :f41 I AA ;I•) �f§ Eh [I]'' ■ •] l ' J The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. ■...
- Page 7 Operation Adjusting the Airflow Rate/SMELL PROOF/CHILD LOCK Operation Adjusting the airflow rate You can adjust the airflow rate to increase your comfort. ■ To change the airflow rate setting • [ .Z. FA NJ . Each pressing of changes the airflow rate setting in sequence. (,t.FANJ Press D-EJ-D·...
-
Page 8: Adjusting The Airflow Direction
Operation Adjusting the Airflow Direction You can adjust the airflow direction to increase your comfort. &CAUTION • Always use a remote controller to adjust the angles of the flaps. Moving the flaps forcibly by hand may cause a malfunction. • Be careful when adjusting the louvres. Inside the air outlet, a fan is rotating at a high speed. ■To start auto swing Upper and lower airflow direction 1 . - Page 9 ■ Operation COANDA/POWER CHILL & ECONO Operations ECONO Operation COANDA Operation ECONO operation enables efficient operation Directs airflow upward.This function prevents air by limiting the maximum power consumption. from blowing directly at users. This function is useful to prevent the circuit ■...
- Page 10 Operation TIMER/GOOD SLEEP Operation TIMER Operation GOOD SLEEP Operations Timer functions are useful for automatically ■ To use GOOD SLEEP OFF TIMER operation. switching the air conditioner on or off in the 0000S�EP . ress C!L) urmg L operation. morning or at night. You can also use the ON •...
- Page 11 Checking the Inverter Output and Temperature Display • When "Good Sleep/Display" key of remote controller push down and hold it for � 2 second then "DISPLAY" IR Signal will be transmitted. • The inverter output and temperature display for the indoor unit shows the current inverter output, indoor temperature, and set temperature.
- Page 12 Operation LED/ 7 SEGMENT BRIGHTNESS Control Operation The brightness of the indicator lamp/ 7 Segment can be adjusted H(high), L(low), or OFF. To set the brightness setting mode. Press(<:�swlNoJ ■ for more than 5 second's. • is displayed on the LCD. 8will ■...
-
Page 13: Care And Cleaning
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. Units ■ Indoor unit and remote controller 1. Wipe them with a dry soft cloth. ■ Front panel 1. Open the front panel. •... -
Page 14: Air Filter
Care Care and Cleaning &CAUTION • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. • When removing or attaching the front panel, use a robust and stable stool and watch your steps carefully. •... - Page 15 1. Replace the old accessory filters with new accessory filters. Accessory Filter Filter type: Titanium apatite deodorizing air purifying filter/ Anti microbial filter [Maintenance] every The accessory filters can be renewed by washing them with water once 6 months. every We recommend replacing them once 3 years.
-
Page 16: Troubleshooting
Troubleshooting Troubleshooting These cases are not problems The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Case Explanation Operation does not start soon. • This is to protect the air conditioner. •... -
Page 17: Check Again
Troubleshooting Troubleshooting Case Explanation The indoor unit gives out • The room odour absorbed in the unit is discharged with the airflow. We recommend you to have the indoor unit cleaned. Please consult your service centre. odour. ■ Immediately after the air conditioner is stopped: The outdoor fan rotates while •... -
Page 18: Disposal Requirements
■ Troubleshooting Troubleshooting Call your service centre immediately & WARNING--------------- ■ when an abnormality (such as a burning smell} occurs, stop operation and turn off the circuit breaker. Continued operation in an abnormal condition may result in problems, electric shock or fire. Consult your service centre. - Page 19 • A short beep indicates non-corresponding codes. • To cancel the code display, hold down [CANCEL) for about 5 seconds. T he code display also cancels itself if the button is not pressed for 1 minute. DAIKIN INDUSTRIES, LTD. Head office: Osaka Umeda Twin Towers South...
- Page 21 3P665364-1Z M22P096E DAIKIN ROOM AIR CONDITIONER INSTALLATION MANUAL tC._JNVERTER - - > MODELS: F/G/MTKM35UV16W F/G/MTKM50UV16U F/G/MTKM60UV16U FTKT35UV16W FTKT50UV16V FTKT60UV16U FTKN35UV16W FTKN50UV16V A/D/F/G/MTKL35UV16W A/D/F/G/MTKL50UV16V A/D/F/G/MTKL50UV16U A/D/F/GTKL60UV16U F/GTKL71UV16T A/F/G/MTKM50UV16VA 3P665364-1Z M22P096E F/GTKC48UV16W F/GTKC48UV16WA...
- Page 22 Safety Precautions • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. • Meaning of WARNING and CAUTION notices � WARNING Failure to follow these instructions properly may result in personal injury or loss of life. �...
-
Page 23: Precautions For Selecting A Location
Accessories ®~® ITEM Remarks ITEM Remarks QTY. QTY. ® Remote controller holder fixing screw (M3 x 20L ® Mounting plate Mounting plate fixing screw (M4 x 25L) <D 4-Core wire (3.7M) 6/7· © Wireless Remote Controller ® Tie wrao ® Accessorv filter @ Dry battery (AAA) 112·... -
Page 24: Indoor/Outdoor Unit Installation Diagram
Indoor/outdoor Unit Installation Diagram • The mounting plate should be installed on a wall which can support the weight of the indoor unit. @Mounting plate ...,. -.;.. @Mountir,gplatel'ixingscrewM4x25L(7pcs.) For type ©®@@(Refer table no. 4) Note: Before installation, mounting plate size & shape must be matched with mounting plate available in the unit, then accordingly follow the installation instruction. 30mm or more from ceiling Cut thermal insulation... -
Page 25: Installation Tips
Installation Tips ■ Installing and Removing the indoor unit. � CAUTION---------- • Installation method 1) Push up. Be sure to wear protection gloves. Hook the claws of the bottom frame to the mounting plate. If the claws are difficult to hook, remove the front grille. Place both hands under the •... -
Page 26: Indoor Unit
Indoor Unit Installing The Mounting Plate • The mounting plate should be installed on a wall which can support the weight of the indoor unit. 1) Temporarily secure the mounting plate to the wall, make sure that the panel is completely level, and mark the boring points on the wall. -
Page 27: Installing The Indoor Unit
Indoor Unit Installing The Indoor Unit ( Right-Side, Right-Back or Right-Bottom Piping) Open the front panel, open the Front grille (If Required), then open the service lid.(Refer to Installation Tips.) Shape the refrigerant pipes. @Mooo•"<> Pass the drain hose and refrigerant pipes through the wall hole. plat e Hang the indoor unit on (A) mounting Plate Refrlgerant... -
Page 28: Drain Piping
Indoor Unit Wiring 1) Strip wire ends (15mm). 2) Match wire colours with terminal numbers on indoor and outdoor unit's terminal blocks and firmly screw wires to the corresponding terminals with the screw. 3) Connect the earth wires to the corresponding terminals. Attach the earth wire so that it is not connected to the fan motor connector. - Page 29 Binding Of Insulation Pipe Sectional view 1. The slit direction should be upward. 2. It should be sealed with vinyl tape without any gap. Hoatlrlou�pipoa,,,er lnsulatilrl L et : = 3. Do not over tighten with vinyl tape. CornrrlJlonwtre '"" � ' Ylnyll!lpe G"'pipe Wrap vinyl tape with the slit of the heat insulation pipe cover facing up so that there are no gap .
-
Page 30: Outdoor Unit
Outdoor Unit Installing The Outdoor Unit • When installing the outdoor unit, refer to and the "Precautions for Selecting a Location" "Outdoor Unit Installation Diagram" ..Flaring The Pipe End � WARNING c,1 o,ocily ,1 ��Remove burrs. Incomplete flaring may result refrigerant gas leakage. Flaring 1) Cut the pipe end with a pipe cutter. -
Page 31: Purging Air And Checking Gas Leakage
Outdoor Unit Purging Air And Checking Gas Leakage � WARNING ------------------------- • Do not mix any substance other than the specified refrigerant (R32) into the refrigeration cycle. • When refrigerant gas leaks occur, ventilate the room as soon and as much as possible. •... -
Page 32: Trial Operation And Testing
Trail Operation And Testing 1. Trial operation and testing • Check that the inter-unit wire is correctly connected. • Trial operation should be carried out in COOL operation. 1-1 Measure the supply voltage and make sure that it is within the specified range. 1-2 Select the lowest programmable temperature. - Page 33 210, 1st FLOOR, OKHLA INDUSTRIAL AREA, PHASE 3, DELHI-110020 Meaning of E-waste under E-Waste (Management) Rules,2022 (E-waste Rules) -Waste electrical and electronic equipment, whole or in part of reject from their manufacturing and repair process, which are intended to be discarded. Our product is RoHS compliant.
