- Page 1 Product Manual LED Chip (CE-02) Original Instruction Version 221208 Copyright © 2022 HYENA INC. All Right Reserved.
-
Page 2: Table Of Contents
Table of Contents Introduction Product Features Product Description .................. 1 Parts Description ..................1 Product Dimension ................... 2 Cable Pin Definition .................. 2 Technical Data Function ....................3 Characteristic .................... 3 Mounting Parameter ................. 3 Connection....................3 LED Indicator Information ................. 3 Certification .................... -
Page 3: Introduction
Introduction This manual is intended primarily for the trained technician to install, disassemble, or maintain the Hyena e-bike system only. Please read all the safety warnings and instructions carefully. Failure to follow the warnings and instructions may result in death or severe injuries. Save this manual for future reference. -
Page 4: Product Dimension
Product Dimension unit: mm Cable Pin Definition Fool-proof of recess DEN/HMI CAN L CAN H VCC+ HYENA E-BIKE SYSTEMS... -
Page 5: Technical Data Function
Bike frame Cable length 55±5 mm Standard connector Hyena 6P male CM-WP408-06M Connection Support to HRA (Hyena Rider Assistant ) & Bluetooth connection Bluetooth 4.2 HST (Hyena Service Tool) LED Indicator Information Motor support level 0 to 3 Battery status... -
Page 6: Mounting
Mount the HMI in. STEP STEP Fasten the screw. Completed. NOTE: The bike image and mounting position seen in the manual may be different from the actual bike, but it will be enough to help you understand related instructions. HYENA E-BIKE SYSTEMS... -
Page 7: E-System Operation
Short press the POWER button to turn on, and long press the POWER button to turn off. When system is on, the indicator shows the battery status. NOTE Always switch off the e-bike system when parking the e-bike or before removing the battery. HYENA E-BIKE SYSTEMS... - Page 8 -The system is activated as soon as you start pedaling. -The e-bike drive output only supports a speed below 25/32 km/h, as soon as you have reached 25/32 km/h, e-system switches off the assistance, then automatically reactivates when your speed is below 25/32 km/h. HYENA E-BIKE SYSTEMS...
- Page 9 Error alert Service tool connection The bottom light flashes red when a system error is When maintaining or diagnosing your e-bike via Hyena detected. Service Tool (HST), follow the software instruction and double click the power button in 0.5 seconds, to connect your e-bike to the computer.
-
Page 10: Safety Instructions
Only clean the product other signs of damage. with a water-dampened soft cloth. • All the component leads shall use original Hyena • Do NOT clean the product or any e-system component components. with pressured water. - Page 11 This page is intended to be blank. HYENA E-BIKE SYSTEMS...
- Page 12 Hyena Inc. Tel: +886 4 23598810 Fax: +886 4 23598610 www.hyena-ebike.com Address: No.25, Jingke N. Rd., Nantun Dist., Taichung City 408, Taiwan (R.O.C.) HYENA E-BIKE SYSTEMS...
