- Page 1 This guideline is applicable for the Hyena e-bike system only LCD Compact EX Product Manual Copyright © 2021 HYENA INC. All Right Reserved. Version 210310 This manual is intended primarily for the trained technician to install, disassemble, or maintain the e-bike.
-
Page 2: Table Of Contents
Content Product features Product Description Parts Description Product Dimension Technical Data Function Characteristic Mounting Parameter Connection Indicator Information Certification Mounting Tool List Accessory List Mounting Instructions Operation Operation Instructions Error Code List Safety Instructions Important Notice Moving and Storage Instructions Maintenance Disposal... -
Page 3: Product Features
Product features Product Description The Hyena LCD Compact EX features all in one function: compact size with complete info and precise digital information, ergonomic large buttons. Supports app and service tool connection via Bluetooth. Parts Description Display screen Power on/off button Up &... -
Page 4: Product Dimension
Product Dimension Cable Pin Definition HYENA E-BIKE SYSTEMS... -
Page 5: Technical Data
SHIMANO BL-MT201 / BL-MT401 Compatible of shifter Do not recommend Connection Bluetooth connection Bluetooth 4.2 BLE Support to HRA (Hyena Rider Assistant ) & HST (Hyena Service Tool) USB connection USB 3.0 TYPE A Support to HST HYENA E-BIKE SYSTEMS... -
Page 6: Indicator Information
Indicator Information Current speed 0~99 Unit in 1 Km/Hour Range 0~99 Unit in 1 KM (Battery with Hyena CAN required) Riding support level Battery status 5 segments Light on indicator Head light icon Bluetooth status Bluetooth icon Error alert Warning icon + Number... -
Page 7: Mounting
• Fasten the hex bolt with 1.0 Nm torque value. • Carefully install is necessary, do not strike it with any tool such as a hammer or wrenches. Step1: Mount the HMI hook on the handlebar Step2: Fasten the hex bolt. HYENA E-BIKE SYSTEMS... -
Page 8: Operation
-The system is activated as soon as you start pedaling. -The e-Bike drive output only supports a speed below 25/45 km/h, as soon as you have reached 25/45 km/h, e-system suspends the motor support, then automatically reactivated when your speed is below 25/45 km/h. HYENA E-BIKE SYSTEMS... - Page 9 Make sure you are ready and stand steady before activating the walk assistance. Do not activate the walk assistance when you ride on the e-bike or if the wheels are not in contact with the ground HYENA E-BIKE SYSTEMS...
-
Page 10: Error Code List
Low side FET of U phase malfunction High side FET of V phase malfunction Low side FET of V phase malfunction High side FET of W phase malfunction Low side FET of W phase malfunction FET malfunction HYENA E-BIKE SYSTEMS... - Page 11 Others Motion assist voltage too high Motion assist voltage too low Button blocked Button communication fail Display panel malfunction USB charge port malfunction Front light malfunction System maintenance notify Bluetooth malfunction Brake sensor malfunction Rear light malfunction HYENA E-BIKE SYSTEMS...
-
Page 12: Safety Instructions
• Do not dispose of e-bikes and their components with • All Hyena e-system manuals and technical documents household waste. are accessible online at "www.hyena-ebike.com". SAVE THESE INSTRUCTIONS •...
