Space Combine
Space Combine shows the combined spaces for each Echo Space in the
panel. None will display next to a Space if a space is not combined with
any other Spaces.
Switching Setup Menu
Switching Setup
1 Output Setup
2 Patch DMX Input
3 Patch sACN Input
4 Emergency Setup
5 Quick Rack Setup
6 Switching Options
Output Setup
Output Setup allows configuration of operation parameters for each
position in the panel. Use [Up] (‡ ) or [Down] (ˆ ) or the numeric
keypad to select a single position, or select multiple positions using
[and] and [thru/#nav]. The selected circuit parameters display.
If you select an output that is a multi-pole relay, the information
shown will be duplicated.
When you select multiple relays or breakers using [and] and
[thru/#nav], the top line updates to show as much information as
possible for the selection. A (+) symbol displays when more information is not shown because
of screen space limitations.
• Mode: Configure the type of load in the output position. See About Menu > Mode on
page 17
‐ When you install a relay at the output position, the options are Normal , Fluorescent ,
Latch/Lock , DALI , and Always On .
‐ When you install a dimmer at the output position, the options are Auto , Forward , or
Reverse phase.
Note:
ERP-DIM-MLV can be set to Mode: Reverse , but this will be ignored by the
dimmer.
• Type: The following types are available per rack.
‐ ERP: 1-pole , 2-pole , Dimmer , None
‐ ERP-FT: 1-pole , None
‐ Sensor IQ: 1-pole , 2-pole , 3-pole , None
• Threshold displays the percentage level at which the relay switches on. The default value
is 1%.
• Space allows configuration of the Space to which the selected outputs are allocated. The
default is Space 1. See
• Zone allows configuration of the Zone to which the selected outputs are allocated. See
Zones on page 9
• Circuit displays the currently assigned circuit number for the dimmer or relay position in
the panel.
19
.
Spaces on page 8
.
.
Power Control Processor Mk2 Configuration Manual
Space Combine
Space 1:
2
Space 2:
1
Space 4:
5,6
Space 5:
4,6
Space 6:
4,5
Output Setup
1
Mode:
Normal
Type:
1-Pole
Threshold:
1%
Space:
1
Zone:
1
Circuit:
1
Allow Manual:
Yes
Min Scale:
1%
