Echo Relay Panel Feedthrough Overview
The Echo Relay Panel Feedthrough (ERP-FT) with Power Control Processor Mk2 provides
professional-quality switching and dimming for up to 48 channels of non-dim loads in a single
panel. Loads are controlled by DMX512 or Ethernet.
A
C
E
A
Note:
Feedthrough. Please call your ETC project manager or customer service representative
for more information.
Overview of Panels
It is possible to retrofit an existing SmartSwitch to an Echo Relay Panel
B
Up to 24 relay modules, top (not shown)
A
Up to 24 relay modules, bottom (not shown)
Locking door, top
D
B
Locking door, bottom
C Power Control Processor Mk2
D Option cards: ERP-CI, ERP-LVD, ERP-DALI
E Install ERP-RTO behind processor
B
6
