Power Setting

NOTE
MDevice automatically recognizes the computer model and the installed operating system.
MDevice differentiates the various systems and displays the configuration dialogues
according to the respective device. So the parameter settings in the configuration dialogues
can be different.
Parameter settings (full set)
Switch-On
Switch-Off
Screen Display
Time Delay
Seconds
10 / 23
To configure which source is allowed to turn on the device.
To configure which source is allowed to turn off the device.
To configure the behavior while receiving ignition off event.
Block input: While receiving ignition off event, all the inputs (ex.
touch, keyboard, mouse) will be blocked.
Show counter: While receiving ignition off event, utility will show a
count down dialog to notify the user.
To configure the delay seconds.
Ignition Off Delay: The waiting time to trigger a OS shutdown event
while ignition off.
Hard Off Delay: The waiting time to trigger a power shutdown event
while ignition off.
Figure 6.4: Count down dialog
NOTE for WEC7 OS:
Due to quick shutdown time at WEC7 operating system it is highly
recommended to leave Hard Off Delay timeout at 1 second.
Increasing this value will cause system warm start followed by EC
switch off.
