DAKE METAL CUTTING VERTICAL BANDSAW
Model 14-10
INSTRUCTIONAL MANUAL
WARNING!
Read and understand all instructions and responsibilities before operating. Failure to follow
safety instructions and labels could result in serious injury.
Dake Corporation
Phone: 800.937.3253
www.dakecorp.com
1809 Industrial Park Dr
Grand Haven, MI 49417
Advertisement
Table of Contents
Related Manuals for Laguna Tools DAKE 14-10
Summary of Contents for Laguna Tools DAKE 14-10
- Page 1 DAKE METAL CUTTING VERTICAL BANDSAW Model 14-10 INSTRUCTIONAL MANUAL WARNING! Read and understand all instructions and responsibilities before operating. Failure to follow safety instructions and labels could result in serious injury. Dake Corporation Phone: 800.937.3253 www.dakecorp.com 1809 Industrial Park Dr Grand Haven, MI 49417...
-
Page 2: Table Of Contents
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Table of Contents DAKE STANDARD LIMITED WARRANTY ............2 RETURN & REFUND POLICY ................4 DAKE STANDARD TERMS & CONDITIONS OF SALE ........5 SPECIFICATIONS ....................6 SAFETY ........................ 6 SET UP ......................... -
Page 3: Dake Standard Limited Warranty
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com DAKE STANDARD LIMITED WARRANTY Finished Machines Dake warrants to the original purchaser the finished machine manufactured or distributed by it to be free from defects in material and workmanship under normal use and service within 1 year (12 months) from the delivery date to the end user. - Page 4 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com When contacting Dake, please have the following information readily available: 1. Model # 2. Serial # 3. Sales Order # Purchasers who notify Dake within the warranty period will be issued a Case number and/or a Return Material Authorization (RMA) number.
-
Page 5: Return & Refund Policy
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com RETURN & REFUND POLICY Thank you for purchasing from Dake! If you are not entirely satisfied with your purchase, we are here to help. Returns All Dake manufactured / distributed machines, parts and couplings include a 30-day return option. -
Page 6: Dake Standard Terms & Conditions Of Sale
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com DAKE STANDARD TERMS & CONDITIONS OF SALE All proposals and quotations for the original sale of our products are subject to the following terms and conditions: ACCEPTANCE OF ORDER: All orders are subject to acceptance by Dake at its main office in Grand Haven, Michigan. -
Page 7: Specifications
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com SPECIFICATIONS Number 988050/988051 Throat Size 14” Horsepower Max Work Height 1 HP 10” Worktable Dimensions 15” x 16” 110V/220V Single Voltage Worktable Tilt Phase, 220V/440V 5° left / 45° right 3-Phase Worktable Height 24-1/2”... - Page 8 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com This is the safety alert symbol. When you see this symbol on your machine be alert to the potential for personal injury. Carefully read all safety messages in these instructions and on your tool safety signs. Employer is responsible to perform a hazard/PPE assessment before work activity.
-
Page 9: Set Up
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com • Always wear approved safety glasses/face shields while using this machine. • Make sure that the machine is properly grounded. • Before operating the machine remove all ties, rings, watches, other jewelry, and roll up sleeves above the elbows. -
Page 10: Blade Selection
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Blade Selection For the operator’s convenience a blade selector chart is located inside the saw cover (top access door). It provides recommended blade speeds, required teeth per inch, and minimum cutting radius for various band widths. -
Page 11: Maintenance
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Upper Blade Wheel Adjustment (Item B & C): If the saw should get out of adjustment and the blade runs off the wheel or runs back against the lip, 1. -
Page 12: Electrical Components
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Blade is dull or worn on one Replace blade side Blade is upside down. Teeth Correct blade orientation must point down. Use the pitch and speed selector on the saw or Incorrect blade pitch for contact Dake if unsure what application... - Page 13 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com 220 Volt Single Phase: 988050 REV032023...
- Page 14 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com 220 Volt 3-Phase 988050 REV032023...
- Page 15 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com 480 Volt 3-Phase: 988050 REV032023...
- Page 16 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com 988050 REV032023...
-
Page 17: Exploded View & Parts List
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com EXPLODED VIEW & PARTS LIST Item Part Number Description 716716 Tension Handle Assembly 86747M Door Latch 87080 Table 300568 Door Handle 300569 Door Latch 716745 Frame Assembly 988050 REV032023... - Page 18 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 716716 Tension Handle Assembly 86828 Tension Handle Body 87104 Tension Handle 716705 Wheel Assembly 300459 Blade Wheel Band 300693 Wheel Bearing 86795 Wheel Blade – Lower/Upper 86803 Axle Wheel –...
- Page 19 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 43450 Socket Cap Screw (3/8”-16 x 1-1/4”) 86827 Pillow Block 86828P Tension Screw 43447 Socket Cap Screw (3/8”-16 x 3/4”) 86824 Wheel Slide – External piece 86825 Wheel Slide –...
- Page 20 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 716749 Saddle Assembly 87081 Table Top Base 87025 Table Lock 43939 Hex Jam Nut (7/16”-20) 44033 Dowel Pin (5/8” x 1-1/2”) 87078 Rocker Rings 87077M Rocker Ring Pointer 43449 Socket Cap Screw (3/8”-16 x 1.0)
- Page 21 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 87029 Guide Bar 300701 Guide Kit 43545 Socket Cap Screw 87028 Upper Guide Swivel 86808 Holder Contour Insert 86806A Insert Contour Guide 1/2" Blade Carbide 86806B Insert Contour Guide 1/2"...
- Page 22 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 300473 Gearbox Pulley 71061 Key for Pulley (3/16” x 3/16” x 1-1/4”) 10077-10 V-Belt 86798 Motor Mounting Axle 86800 Motor Mounting Block 43450 Socket Cap Screw (3/8”-16 x 1-1/4”) 43414 Socket Cap Screw (1/4”-20 x 3/4") 300473...
- Page 23 Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 300666 Worm Gear (Bronze) 86784 80 Tooth Gear 300456 4-Lead Worm 300646 24 Tooth Gear 5072-00 Gearbox Bearing 5073-00 Gearbox Bearing 86785 Main Drive Shaft 86781 Gearbox - Short Axel 86783...
-
Page 24: Ordering Information
Dake Corporation 1809 Industrial Park Dr Grand Haven, MI 49417 www.dakecorp.com Item Part Number Description 86786 Gearbox Spacer (1” OD) 300449 Woodruff Key #13 300451 Woodruff Key #5 300472 Bearing Seal 300490 Gearbox Gasket 300491 Gearbox Gasket 300589 Dowel (3/16” x 12) 43412 Socket Cap Screw (1/4”-20 x 1/2”) 43414...
