Connections and Descriptions
2
1
1 Coiled Link cable (shown) or Extension Reel Cable (not shown) plugs directly
into the CCU.
2 Protective Dust Cover.
3 CCU Location Pins.
4 Friction Brake.
5 Self-Leveling Axial camera - CAM025 (see opposite)
NOTE!
The CCU can power the coiler without the use of
External Charger SPP-PSU or Proteus Battery Pack BPP24.
Version A
3
3
