Survey Keys; Distance - Envirosight Verisight Pro+ Original Instruction Manual

Survey Keys

The Survey keys cluster features three keys:
A. Distance B. Text C. Survey Features

Distance

1 Press the Distance key.
The Distance functions will be displayed on screen
2
Select the required function:
Zero F1 (Red key )
Offset F2 (Blue key)
Move F3 (Yellow key) Use the cursor control Left Arrow,
Hide F4 (Green key ) Hides or shows the distance from the
Color F5 (Magenta)
Units F6 (Cyan)
Version A
A B C
Resets the distance to 00.0.
Sets the distance to your preferred value.
Up Arrow, Right Arrow and Down Arrow
to re- position the on-screen text.
display.
Change the color and/or outline of the
screen text.
Set the units of measure:
0.00'/ 0'.0"/0.00m/0.00cm.
Envirosight Verisight Pro +
37
