Camera Keys

The Camera keys cluster features six keys:

1 Zoom

2 Camera Sweep
3 Illumination
4 Home
5 Focus Minus
6 Focus Plus
Zoom
Press the Zoom key.
Pressing this key once will zoom in by a factor of 1.5, pressing a second time
will increase the zoom ratio to 2 and pressing a third time will increase it to 3.
Pressing this key a fourth time returns the picture to normal view. At each stage
of zoom, the area of the total survey picture which is being viewed on the screen
is shown as a red box on a white background in the bottom left of the picture.
The area which is viewed in zoom mode can be moved around the survey picture
using the cursor control Left Arrow, Up Arrow, Right Arrow and Down Arrow
keys.
If the survey picture is zoomed in during a recording then the zoomed view will
be recorded together with the red on white symbol to show which area of the
survey picture is being viewed.
Version A
3
1 2
5
Envirosight Verisight Pro +
4
6
53
