At each stage of zoom, the area of the total survey picture which is being viewed
on the screen is shown as a red box on a white background in the bottom left of
the picture.
The area which is viewed in zoom mode can be moved around the survey picture
using the cursor control Left Arrow, Up Arrow, Right Arrow and Down Arrow
keys.
If the survey picture is zoomed in during a recording then the zoomed view will
be recorded together with the red on white symbol to show which area of the
survey picture is being viewed.

Snapshot Capture

While a survey is being recorded or played back, a still image may be captured
and stored by pressing the Snapshot key . The still image will be stored as a
.jpg still image using the default filename format.
Snapshots may be taken while recording or playing back a survey. If a snapshot is
taken while the picture is zoomed in (see page 42), then it will be the zoomed
image which is stored as the snapshot.
