CCU210 - Control Unit

The control unit CCU210 is a robust and portable control unit for the Verisig ht Pro+
system. It controls the functions and reports the status of the attached coiler and
camera. It has the following features:
• Scalable internal solid state storage (32GB minimum)
• Data transfer via USB and SD card
• Sunlight readable display (SVGA 800x600 pixels)
• Video recording in MPEG-4 (WinCan compatible)
• Pictures saved in JPG format
• Customizable color on screen text overlay
• Video output of live video with on-screen text
• Ergonomic design
• IP54 rated
The control unit CCU210 enables the operator to record video and photographic
surveys, generate survey reports, and export the data via USB or SD card. The
control unit can generate on screen text that is overlaid onto the recorded video
in various colors and positions, allowing easy customization.
