6K-ERB08 User's Guide

Signal cables

50
1
Details on the C100MMS-x cable are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=104&pf_id=1514.
Pins 1-50 are on the long side
of the "D" connector.
50
1
Details on the C100HD50-x cable are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=104&pf_id=1203.
2
50
100
51
Figure 2-1. C100MMS-x cable
100
51
Pins 51-100 are on
the short side of
the "D" connector.
Stamped "Pins 51-100".
Figure 2-2. C100HD50-x cable
1
49
Figure 2-3. C50FF-x cable
Strain relief is
49
stamped "Pins 1-50".
Key
1
The red stripe
identifies pin # 1
99 100
Key
51 52
Strain relief is
The red stripe
identifies pin # 51
The red stripe
identifies pin # 1
2-7
Installing the 6K-ERB08
50 100
1 51
50
2
2 1
50 49
