6K-ERB08 User's Guide
Figure 2-4. 6K-ERB08 board jumpers and external power connectors
Power source
Set the power source with jumper
following sources.
The 6000 Series control board's internal +5 V power supply (default)
Your computer's +5 V power supply, or external +5 V supply (power cable supplied)
AC adapter (supplied)
Figure 2-5
shows the
+5BD
Internal power
Internal power
from the MCC board
from the MCC board
External +5 V PC power connections
You can power the 6K-ERB08 with your computer's +5 V power supply using the
was shipped with the board. Each end of the cable has a keyed MOLEX type connector. To connect to your
computer's internal power connectors, do the following:
1.
Turn your computer off, remove the cover, and insert your board into an available PCI slot.
2.
Close your computer and turn it on.
3.
Turn off power to the computer and remove the cover.
4.
Connect one end of the C-PCPOWER10 power cord to one of your computer's internal power connectors.
If necessary, refer to your computer's user manual for the location of the power supply connectors.
5.
Run the power cable out the back of the computer through an expansion slot or other opening, and replace
the cover on the computer.
(labeled
JP1
jumper setting for each power source.
POWER IN
External power from
External power from
the computer's power supply
the computer's power supply
Figure 2-5. Power source jumper JP1configurations
). You can power the 6K-ERB08 using one of the
POWER IN
+5PC
2-9
Installing the 6K-ERB08
9V EXT
External power from
External power from
an AC adapter
an AC adapter
cord that
C-PCPOWER-10
