Owner's Instruction and Operation Manual
Model Number:
SW500
Report Number: F22-781
Tested Per EPA Methods 28R and ASTME2515
and ASTME2780 and CSAB415.1 Certified to
UL 1482-2022 and ULC-S627:2021
Mobile home/transportable buildings approved
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For your
safety, follow the installation instructions. Never use make-shift compromises during the
installation of this heater. Contact local building or fire officials about permits, restrictions
and installation requirements in your area. NEVER OPERATE THIS PRODUCT WHILE
UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury, or
even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
© 2023 Breckwell Hearth, South Pittsburg, TN 37380
Save These Instructions In A Safe Place For Future Reference.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
PH. 423-403-4031
853952-0304M
www.P65warnings.ca.gov
