Owner's Instruction and Operation Manual
Model Number:
SP22(i)
Report Number: F21-687
Certified to ASTM E1509-12 (2017),
ULC-S627-00-REV1, and ULC S628
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For your
safety, follow the installation instructions. Never use make-shift compromises during the
installation of this heater. Contact local building or fire officials about permits, restrictions
and installation requirements in your area. NEVER OPERATE THIS PRODUCT WHILE
UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury, or
even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
© 2022 Breckwell Hearth, South Pittsburg, TN 37380
R
Save These Instructions In A Safe Place For Future Reference.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
PH. 423-403-4031
852178H-0805L
www.P65warnings.ca.gov
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Breckwell Maverick SP22i
Summary of Contents for Breckwell Maverick SP22i
- Page 1 State of California to cause emissions standards. cancer, birth defects, and/or other reproductive harm. For more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2022 Breckwell Hearth, South Pittsburg, TN 37380 PH. 423-403-4031...
- Page 2 INTRODUCTION This manual describes the installation and operation of the Breckwell, SP2(i) wood heater. This heater meets the 2020 U.S. Environmental Protection Agency's emission limits for wood heaters sold after May 15, 2020. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 4,814 to 32,788 Btu/hr, 0.49 g/hr, and 63% efficiency.
-
Page 3: Installation Checklist
Your wood stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified. org/public/find-an-nfi-pro/ For customer service, please contact your Breckwell dealer. COMMISSIONING CHECKLIST This checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference. -
Page 4: Installation
OR SEVER THE GROUNDING PLUG. DO NOT ROUTE THE ELECTRICAL CORD UNDERNEATH, IN FRONT OF, Breckwell highly recommends your stove be installed by a OR OVER THE HEATER. DO NOT ROUTE THE CORD IN qualified NFI (US) or WETT (Canada) technician. To find the... -
Page 5: Combustion Air Supply
(sidewall) air. A 2” (51 mm) inside diameter metallic pipe, either flexible or rigid, may be attached to the inlet at the stove’s SIDEWALL CLEARANCES rear as shown. A rodent guard (minimum 1/4” (7 mm) © 2022 Breckwell Hearth... -
Page 6: When Outside Air Is Not Used
This is a pressurized exhaust system. RODENT All vent connector joints must be sealed with 500°F (260°C) VENTILATED CRAWL SPACE GUARD RTV silicone sealant to ensure consistent performance and © 2022 Breckwell Hearth... -
Page 7: Vertically With New Chimney System
CLEANOUT the possibility of smoke spillage in the event of a loss of negative pressure. APPLIANCE 6. Attach cap and seal outside wall thimbles with non- 45° ELBOW hardening waterproof mastic. © 2022 Breckwell Hearth... -
Page 8: Vertically Into Existing Chimney System
1/4” (7 mm) stainless steel sheet metal screws. Seal all joints and 3. Install a blanking plate and the chimney pipe, and if seams around the collar. used the outside air pipe, as shown in. © 2022 Breckwell Hearth... -
Page 9: Insert Installations
BRECKWELL ZC 2. Attach cerablanket wrap (not included) to that end of ADJUSTABLE LEGS vent pipe that will connect to the stove. Use 12” (305 FIGURE 14 © 2022 Breckwell Hearth... -
Page 10: Exhaust Pipe Installation
LEVELING BOLTS OUTSIDE WARNING: COMBUSTION AIR HEARTH • IF FIREPLACE BEEN INSTALLATION MODIFIED ACCOMMODATE THE FIREPLACE INSERT A METAL TAG SHALL BE ATTACHED TO THE FIREPLACE. • DO NOT USE MAKESHIFT COMPROMISES DURING INSTALLATION. © 2022 Breckwell Hearth... - Page 11 THE METAL SIDES, FRAME MEMBERS, OR OTHER THE INSERT ON be listed per UL 127. Installation must include a full height STRUCTURAL COMPONENTS OF THE FACTORY BUILT RAISED FIREPLACES FIREPLACE MAY NOT BE REMOVED OR ALTERED © 2022 Breckwell Hearth...
-
Page 12: Electrical Installation
120V AC with no more than 5% variation. 1/4” (7 mm) lag bolts that are long enough to go through Breckwell cannot accept responsibility for poor performance both a hearth pad, if used, and the floor of the home. Refer or damage due to inadequate voltage. -
Page 13: Operation
DO NOT USE THIS CONTROL DURING NORMAL thermodisc. If the high temp thermodisc does trip (see OPERATION BECAUSE IT COULD SMOTHER THE FIRE AND “Safety Features” section of this manual). LEAD TO A DANGEROUS SITUATION. © 2022 Breckwell Hearth... -
Page 14: Manual Mode
• In this mode, the stove will operate only from the control 4. Materials containing plastic; panel as detailed in the “Operation” section of this 5. Waste petroleum products, paints or paint thinners, or owner’s manual. asphalt products; © 2022 Breckwell Hearth... -
Page 15: Proper Fuel
Do not burn wet pellets. The stove’s performance permanent damage to the heater. depends heavily on the quality of your pellet fuel. Avoid © 2022 Breckwell Hearth... -
Page 16: Opening Door
The stove will have to fully shut down and turn sidewalls and bottom of the hopper. off before you will be able to restart the stove. b. Cleaning heat exchanger tubes (see “Cleaning” section of this manual). ROOM AIR FAN c. Scrape ashes from burnpot. © 2022 Breckwell Hearth... -
Page 17: Shutdown Procedure
NOTE: Opening the stove door for more than 30 seconds during operation will cause enough pressure change to activate the air switch, shutting the fuel feed off. Close the door and press “On/Off” button to continue operation of your stove. © 2022 Breckwell Hearth... -
Page 18: Maintenance
BE PLACED ON A NON-COMBUSTIBLE SURFACE OR ON relatively cool chimney flue or a newly started fire or from a THE GROUND, WELL AWAY FROM ALL COMBUSTIBLE slow-burning fire. As a result, creosote residue accumulates MATERIALS, PENDING FINAL DISPOSAL. © 2022 Breckwell Hearth... -
Page 19: Removal And Replacement Of Broken Door Glass
An authorized dealer must perform all repairs in, if the collar on the burnpot attached to the fresh air FIGURE 27 involving door glass. tube is not pushed back to meet the firebox wall, the automatic igniter will not work properly. © 2022 Breckwell Hearth... -
Page 20: Spring Shutdown
AND REPAIR FOR PROPER OPERATION. IT IS AGAINST Gaskets around door and door glass should be inspected FEDERAL REGULATIONS TO OPERATE THIS WOOD and repaired or replaced when necessary. HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2022 Breckwell Hearth... -
Page 21: Troubleshooting Guide
Air switch has failed (very rare). off the stove and the air switch first and make sure it is clear). If you hear a click, the air switch is working. BE CAREFUL! TOO MUCH VACUUM CAN DAMAGE THE AIR SWITCH. © 2022 Breckwell Hearth... - Page 22 The control board is not sending power to There should be a 5-volt (approximately) current going to the POF thermodisc the POF thermodisc or other auger system after the stove has been on for 10 minutes. components. © 2022 Breckwell Hearth...
- Page 23 If there is Bad control board not a full current going to the auger motor when the fuel feed light is on, you have a bad control board. © 2022 Breckwell Hearth...
- Page 24 RTV. The gasket on the combustion blower has Inspect both gaskets on the combustion blower to make sure they are in gone bad. good shape. © 2022 Breckwell Hearth...
- Page 25 All joints should be properly sealed. Also, clean your stove following instructions in “Maintenance.” If problem persists, contact your dealer. © 2022 Breckwell Hearth...
-
Page 26: Electrical Diagram
Other information that may be needed would be the part number and part description of the item(s) in question. Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact your Breckwell dealer or visit www.Breckwell.com Model Information Model Number Dealer’s Name... -
Page 27: Replacement Parts
REPLACEMENT PARTS © 2022 Breckwell Hearth... - Page 28 88100 Gasket, Exhaust Blower IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ORIGINAL MANUFACTURERS PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM THE APPLIANCE MANUFACTURER. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2022 Breckwell Hearth...
-
Page 29: Service Record
Engineer Name: _________________________________ Engineer Name: _________________________________ License No.: _____________________________________ License No.: _____________________________________ Company: ______________________________________ Company: ______________________________________ Telephone No.: __________________________________ Telephone No.: __________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: __________________________________ Items Replaced: __________________________________ © 2022 Breckwell Hearth... - Page 30 NOTES © 2022 Breckwell Hearth...
- Page 31 NOTES © 2022 Breckwell Hearth...
