- Page 1 Astoria DMB-T/H Storage TV Dongle Reference Design Guide Document No. 001-54438 Rev. *B Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 880.858.1810 Phone (Intnl): 408.943.2600 http://www.cypress.com...
- Page 2 © Cypress Semiconductor Corporation, 2009-2015. The information contained herein is subject to change without notice. Cypress Semiconductor Corporation assumes no responsibility for the use of any circuitry other than circuitry embodied in a Cypress product. Nor does it convey or imply any license under patent or other rights. Cypress products are not warranted nor intended to be used for medical, life support, life saving, critical control or safety applications, unless pursuant to an express written agreement with Cypress.
-
Page 3: Table Of Contents
2.1.3 Firmware..............................5 2.1.4 Hardware ..............................5 Device Functionality ..............................6 Device Connection ..............................6 USB Download ..............................7 2.4.1 BDA Driver Installation..........................9 TV Player Setup ..............................13 Appendix ..................................14 Sample Board Photos............................14 Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... -
Page 4: Introduction
Description of Change July 02, 2009 PRKU Initial version of Reference Design Guide June 27, 2012 RSKV No change. Sunset review August 3, 2015 RSKV No change. Sunset review Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... -
Page 5: Reference Design Package Contents
Contains the layout files for PCB manufacturing NetList Contains the Netlist files for the design Schematics Contains the schematics files of the design in .pdf and .dsn format Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... -
Page 6: Device Functionality
Connect the antenna to the TV dongle and plug it into the USB port. Place the antenna near a window. This helps you get a better signal reception. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... -
Page 7: Usb Download
Development Tools, from the following link: http://www.cypress.com/?rID=34870 When the device is connected, open the CY Console using the path: Start > All Programs > Cypress > USB > CY Console Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... - Page 8 Click on Options and select EZ-USB Interface. A USB device is now detected. In the Download tab, select the .hex file from the Firmware folder of the Reference Design package. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B...
-
Page 9: Bda Driver Installation
BDA driver, follow these instructions. Click on the No, not this time option and then click Next. Select Install from a list or specific location (Advanced) and then click Next. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... - Page 10 Select Don’t Search, I will choose the driver to install and then click Next. Again click Next. Click Have Disk and browse to the location where the cydmbth.inf is saved. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B...
- Page 11 Reference Design Package Contents Select DMB-TH TV USB 8G75 and click Next. A pop up window appears as shown in the figure below. Click on Continue Anyway. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B...
- Page 12 Reference Design Package Contents When the installation is complete, the new device appears in the Device Manager. The driver is installed and the hardware is ready to use. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B...
-
Page 13: Tv Player Setup
HDTV player 4.0 should be installed. Click Scan Channels. Select your country or input the frequency directly; click OK to scan. You are able to watch HDTV if a signal is detected. Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B... -
Page 14: Appendix
Appendix 3. Appendix 3.1 Sample Board Photos Sample CY_Astoria_LGS_DMB-TH_Storage_TV Dongle Board Top View Sample CY_Astoria_LGS_DMB-TH_Storage_TV Dongle Bottom View Astoria DMB-T/H Storage TV Dongle Reference Design Guide, Doc. No. 001-54438 Rev. *B...
