- Page 1 USER MANUAL ENGLISH Shark Spot Two Product code: 45030 Firmware version: 2.0.1 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Shark Spot Two Preface Thank you for purchasing this Showtec product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Shark Spot Two Table of contents Introduction ................................4 Before Using the Product ..........................4 Intended Use ............................... 4 Product Lifespan ..............................4 LEDs Lifespan ............................... 4 Text Conventions ..............................4 Symbols and Signal Words ..........................5 Symbols on the Information Label ........................5 Safety .................................. - Page 4 Shark Spot Two Maintenance ..............................30 Safety Instructions for Maintenance ......................30 Preventive Maintenance ..........................30 Basic Cleaning Instructions ........................30 Corrective Maintenance ..........................31 Replacing the Fuse .............................31 Deinstallation, Transportation and Storage ....................32 Instructions for Deinstallation ..........................32 Instructions for Transportation ........................32 Storage ................................32 10.
-
Page 5: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Showtec Shark Spot Two ● Schuko to Power Pro cable (1,5 m) ● Safety eye ●... -
Page 6: Symbols And Signal Words
Shark Spot Two ● References: References to chapters and parts of the device are in bold lettering, for example: “Refer to 2. Safety”, “turn the adjustment handle (05)” ● 0–255: Defines a range of values ● Notes: Note: (in bold lettering) is followed by useful information or tips Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. -
Page 7: Safety
Shark Spot Two Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children For adult use only. - Page 8 Shark Spot Two WARNING Risk of epileptic shock Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at strobe lights. Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device.
-
Page 9: Requirements For The User
Shark Spot Two Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded. ● The safety devices are not damaged. ●... -
Page 10: Description Of The Device
Description of the Device The Showtec Shark Spot Two is a 90-watt LED moving head suitable for indoor use. Fifty percent more powerful than the Shark Spot One (45023), it has seven dichroic colours plus white and a 3-facet prism, giving it everything it needs to put on a colourful and dynamic light display. -
Page 11: Bottom View
Shark Spot Two Bottom View 11) Mounting holes for quick lock bracket 12) Safety Eye hole Fig. 04 Product code: 45030... -
Page 12: Product Specifications
Shark Spot Two Product Specifications Model: Shark Spot Two Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 130 W Fuse: F4AL, 250 V Physical: Dimensions: 246 x 154 x 355 mm (L x W x H) (including bracket) Weight: 6,2 kg Optics:... -
Page 13: Dimensions
Shark Spot Two Dimensions Fig. 05 Fig. 06 Fig. 07 Fig. 08 Product code: 45030... -
Page 14: Installation
Shark Spot Two Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If trussing systems are used, installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning rigging and trussing. Personal Protective Equipment During installation and rigging wear personal protective equipment in compliance with the national and site-specific regulations. -
Page 15: Rigging
Shark Spot Two Rigging The device can be positioned on a flat surface or mounted to a truss or other rigging structure in any orientation. Make sure that all loads are within the pre-determined limits of the supporting structure. CAUTION Restrict the access under the work area during rigging and/or derigging. -
Page 16: Connecting To Power Supply
Shark Spot Two Connecting to Power Supply DANGER Electric shock caused by short-circuit The device accepts AC mains power at 100–240 V and 50/60 Hz. Do not supply power at any other voltage or frequency to the device. This device falls under IEC protection class I. Make sure that the device is always electrically connected to the ground (earth). -
Page 17: Setup
Shark Spot Two Setup Warnings and Precautions DANGER Electric shock caused by short-circuit Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. Stand-alone Setup When the Shark Spot Two is not connected to a controller or to other devices, it functions as a stand- alone device. -
Page 18: Dmx Cables
Shark Spot Two DMX Cables Shielded twisted-pair cables with 3-pin XLR connectors must be used for reliable DMX connection. You can purchase DMX cables directly from your Highlite International dealer or make your own cables. If you use 3-pin XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable operation of the DMX network. -
Page 19: Dmx Linking
Shark Spot Two DMX Linking To connect multiple devices on one DMX data link, follow the steps below: 01) Use a 3-pin DMX cable to connect the DMX OUT connector of the lighting controller to the DMX IN connector of the first device. 02) Connect the first device’s DMX OUT connector to the second device’s DMX IN connector with a 3-pin DMX cable. -
Page 20: Operation
Shark Spot Two Operation Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for. This device is intended for professional use as a moving head. It is not suitable for households and for general lighting. -
Page 21: Control Panel
Start-up Upon start-up the display shows a splash screen with the Showtec logo. Afterwards the display shows the start screen. The start screen provides information about the temperature of the LEDs, the DMX starting address of the device, and the selected DMX channel mode: Press the ENTER button or the UP/DOWN buttons to enter the main menu. -
Page 22: Menu Overview
Shark Spot Two Menu Overview Product code: 45030... -
Page 23: Main Menu Options
Shark Spot Two Main Menu Options The main menu has the following options: 01) Press the UP/DOWN buttons to navigate through the main menu. 02) Press the ENTER button to open the submenus. Note: One of the submenus require a password. The default password is 018. DMX Address In this menu you can set the DMX starting address of the device. -
Page 24: Running Mode
Shark Spot Two Running Mode In this menu you can set the control mode of the device. 01) Press the UP/DOWN buttons to select one of the 3 operation modes. The display will show: 02) The operation modes are: DMX: DMX mode (Also used for Master-Slave setting) ... -
Page 25: Settings
Shark Spot Two Settings In this menu you can set the Shark’s settings. 01) Press the UP/DOWN buttons to select the desired submenu. The display will show: 02) Press the ENTER button to enter the desired submenu. 03) The submenus are: ... -
Page 26: Calibration
Shark Spot Two Calibration In this menu you can set the initial movement and color parameters of the Shark. 01) Once you have chosen CALIBRATION (see page 25) press the ENTER button to open the menu. 02) You will now need to insert the password, in order to access the menu. Press the UP/DOWN buttons until the display shows 018 and press the ENTER button to confirm. -
Page 27: Remote Control
Shark Spot Two Remote Control Fig. 15 Button Function Description Double-press the button (within 5 seconds) to switch IR ON/OFF mode ON or OFF. Reset Press the button to reset settings. LEDs ON/OFF Press the button to switch the LEDs ON/OFF. Colors Press the button to switch colors. -
Page 28: Dmx Channels
Shark Spot Two DMX Channels 8 channels, 15 channels 8 CH 15 CH Function Value Setting 000–255 Pan adjustment 0°–540° Pan Fine 000–255 Pan adjustment, 16-bit Tilt 000–255 Tilt adjustment 0°–210° Tilt Fine 000–255 Tilt adjustment, 16-bit Pan/Tilt Speed 000–255 From fast to slow Master Dimmer 000–255... -
Page 29: Rotating Gobo Wheel And Color Wheel
Shark Spot Two 000–127 Gobo indexing (0–720°) 128–188 Counter-clockwise gobo rotation, from fast to slow Gobo rotation 189–193 Stop 194–255 Clockwise gobo rotation, from slow to fast Focus 000–255 Motorized focus, from small to big 000–127 Prism Off Prism (3-facet) 128–255 Prism On 000–005... -
Page 30: Troubleshooting
Shark Spot Two Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. - Page 31 Shark Spot Two Maintenance Safety Instructions for Maintenance DANGER Electric shock caused by dangerous voltage inside Disconnect power supply before servicing or cleaning. Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ● All screws used for installing the device or parts of the device are tightly fastened and are not corroded.
- Page 32 Shark Spot Two Corrective Maintenance The device does not contain user-serviceable parts Do not open the device and do not modify the device. Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for more information. Replacing the Fuse DANGER Electric shock caused by short-circuit...
- Page 33 Shark Spot Two Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and derigging of the device.
- Page 34 Shark Spot Two Product code: 45030...
- Page 35 Shark Spot Two Product code: 45030...
- Page 36 ©2022 Showtec...
