6. Connections, LED Indication
1
Multifunction Port
Designation Sensor con-
nector pin
+Ub
GND
+Laser on/off
-Laser on/off
RS422
/RS422
In1
GND-In1
In2
GND-In2
In3
GND-In3
Shield
2
3
10
4
1
5
9
6
8
7
12
12-pin. screw connector, view on solder side (cable)
scanCONTROL 2900/2950BL
2
Cable color
PCR3000-x
9
2
3
1
12 Red-blue
11 Gray-pink
6
4
5
8
10
7
Housing
GND: galvanically isolated from IN1, IN2, IN3, RS422,
laser on/off
laser on/off: input galvanically isolated from GND,
11
IN1, IN2, IN3, RS422
IN1, IN2, IN3, RS422: inputs galvanically isolated
from GND and laser on/off
1 Ethernet port
2 Multifunction port (Power supply, I/O)
Red
(rated value 24 V); max. 5 W
Blue
White
Brown
Yellow
Green
Pink
Gray
Purple
Black
Black Not electrically connected to GND
Notes
+ 11 V - 30 V DC
0 V
Available with SI option
RS422
input or output
Switching input In1
Ground connection In1
Switching input In2
Ground connection In2
Switching input In3
Ground connection In3
