6.2 RJ45 Ports

The Front Panel has 4 RJ45 Ports and which are all 10/100/1000 BASE-T Ports – note that these
are all PoE+ capable ports, in accordance with the IEEE 802.3at Standard. All of the RJ-45 ports
are auto MDI/MDI-X compatible and can operate in Full/Half Duplex Modes via auto-negotiation.
The remaining SFP port is 100/1000 BASE-FX and accept a wide range of SFP modules.

6.3 Power Connections

Model
PDT-NSU-7104-MP-SF-I
Note: All Power Supplies should provide over-current and short-circuit protection and should
have a capacity rating to meet the required output current for the device.

6.4 PoE Output

PDT-NSU-7104-MP-SF-I

6.5 PoE Budget

The total PoE Power Budget varies depending upon input voltage, as shown in the following table:
V-
GND
Model
Supply Voltage
Total PoE Budget
V+ Power Input
12-48VDC
802.3af 802.3at 802.3bt
● ●
+12VDC +24VDC +48VDC
60W 90W 120W
