10. Hardware Specification

ETHERNET
Forwarding and Filtering Rate
INTERFACE
PoE
ENVIRONMENTAL
Operating Temperature
ELECTRICAL
Short-Circuit Protection
MECHANICAL
INDICATORS
Standards
Packet Buffer
Packet Length
MAC Address Table
Exchange Property
Wired
Fiber
Standard
Port Type
Power Pin Assignment
Power Budget
Storage Temperature
Relative Humidity
MTBF
Operating Voltage
Power Consumption
Reverse Polarity
Dimensions
Weight
Casing
Mounting
PWR
FX
L/A
SPD
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3at Powe over Ethernet Plus
14,880pps (10Mbps)
148,800pps (100Mbps)
1,488,000pps (1000Mbps)
1Mbits
10KB
8K
Backplane Bandwidth 20Gbps
Packet Forwarding Rate 14.88Mbps
4 x 10/100 BASE-T RJ45
1 x 1000 BASE-FX SFP
IEEE 802.3af/ IEEE 802.3at
RJ45
4/5 (+) 7/8 (-)
48VDC Supply: 120W
24VDC Supply: 90W
12VDC Supply: 60W
-40°C to +80°C
-40°C to +85°C
5% - 95% non-condensing
>200,000 hours
12-48VDC (Terminal Block Connector)
6W
Auto-Reset
Protected
95mm x 70mm x 29mm
250g
Aluminium
DIN Rail & Wall Mount
Power Status
Fiber Port Status
Link Activity
Link Speed
