User Manual
IKP1000 Transmitter

Maintenance

IKP1000 Maintenance Recommendations

Maintenance tips quick reference
IKP1000 Troubleshooting
LED color | Frequency Pulse Frequency
Green | continuous
Green | pulses
Red | slow pulses
Red | fast pulses
Red | double pulses
Red | continuous
8 | © Danfoss | October 2019
This product is designed for use in an industrial environment that may shorten the product's lifespan. Use
these recommendations to maximize the lifespan of the product.
•
Use the hook/belt provided with the transmitter to prevent the transmitter from falling.
•
Do not clean the transmitter with solvents or pressurized water; use a damp cloth or soft brush for
cleaning.
•
Be sure to recharge or replace battery regularly.
•
If the push buttons show signs of deterioration, contact the Authorized Technical Service.
•
Check the battery for correct contacts, otherwise replace them.
The transmitter has status monitoring LED's which help identify irregularities. The most common signals
are contained in the table below:
Description
The transmitter works properly. Operation
mode is OK.
STANDBY mode. If transmitter is 4 minutes
ON and no action has been taken.
Low battery signal.
EEPROM module missing or corrupted.
A maneuver is activated at transmitter start up
process; may indicate hardware damage if no
order is active.
General hardware failure or damage.
Action
No action needed.
Press START to return to operation mode.
In 5 minutes you need to replace with full
battery.
Check EEPROM module or reprogram if
necessary.
Release maneuver or replace transmitter if
necessary.
Replace transmitter
