10 Using the Anybus Defender Compact in gateway mode
Network A
Network B
WAN
192.168.0x/24
172.16.0x/24
If you use the Anybus Defender Compact in gateway mode, start the device in Bridge mode with active
packet filter.
After booting, both the packet filter and the learning mode are active.
That is, the WAN > LAN and LAN > WAN transitions are blocked.
All pending connection attempts are detected.
Use gateway mode if your network is on the LAN and WAN side of the Anybus Defender Compact in
different network segments (see graphic above with the IP example addresses).
- 13 -
