BASIC INSTRUCTION SHEET No. 52585519EN (2018/12/01)
THIS ALL-TERRAIN AERIAL WORK PLATFORM IS DESIGNED TO OPERATE ON NATURAL OR UNDEVELOPED LAND,
This document is a short recap on how to operate an aerial work platform and should in no way be substituted for the manual required by Directive 2006/45/EC,
which should be read and understood by the operator beforehand and stored in the basket of the aerial work platform.
All the instructions, including the safety instructions, described in the manual but not included in this document should be implemented and enforced.
PLATFORM WEIGHT
- Unladen
- At rated load
BASKET CAPACITY
- 3 people
PLATFORM SPEED
- Working speed
- Slow transport speed
- Tortoise transport speed
- Ramp transport speed
- Hare transport speed
2
35
34
31
33
32
39
21A
20
37
22
38
The operator must have received proper training and must comply with the applicable road traffic rules.
13,600 kg
13,950 kg
350 kg
1.0 km/h
1.8 km/h
2.5 km/h
F
2.5 km/h
D
5.4 km/h
6C
6A
6D
6B
8
1
3
7
4
5
15
29
30
28A
17
28B
36
27
14
24
21B
23
18
19
OR CONSTRUCTION SITES.
t
t
IMPORTANT

TECHNICAL CHARACTERISTICS

E
B

GROUND CONTROL PANEL

1 - EMERGENCY STOP BUTTON
6E
2 - IGNITION SWITCH
3 - ENGINE STARTER BUTTON
6F
4 - ENGINE STARTING MODE BUTTON
5 - CONTROL SELECTION SWITCH ON THE GROUND/IN THE BASKET
6G
6 - CONTROL KEYS:
6H
6I
6J
6K
6L
7 - INTERFACE SCREEN NAVIGATION KEYS
8 - INTERFACE SCREEN

CONTROL PANEL IN THE BASKET

14 - EMERGENCY STOP BUTTON
15 - PREHEAT INDICATOR LIGHT
16
16 - ENGINE STARTER BUTTON
25
17 - HORN BUTTON
18 - BASKET ROTATION SWITCH
19 - NOT USED
20 - NOT USED
21 - JIB ZERO POSITION INDICATOR LIGHT AND BUTTON
22 - JIB AND TURNTABLE CONTROL HANDLE
23 - MAIN ARM AND TELESCOPE CONTROL HANDLE
24 - NOT USED
25 - DRIVING/STEERING CONTROL HANDLE
26
26 - DRIVING SPEED SELECTION SWITCH
28A - FRONT WHEEL ALIGNMENT INDICATOR LIGHTS
28B - REAR WHEEL ALIGNMENT INDICATOR LIGHTS
29 - TURNTABLE ORIENTATION MORE THAN 90° INDICATOR LIGHT
30 - DIFFERENTIAL LOCKING BUTTON
31 - TILTING/OSCILLATION ALARM LIGHT
32 - "USE ON SLOPE" BUTTON
33 - NOT USED
34 - OVERLOAD ALARM LIGHT
35 - FAULT ALARM INDICATOR LIGHT
36 - LOW FUEL LEVEL ALARM LIGHT
38 - GENERATOR BUTTON (OPTION: GENERATOR)
39 - RESET BUTTON (OPTION: "SAFEMANSYSTEM")
220 TJ+
A
A1
G
6A - RAISE THE JIB
6B - LOWER THE JIB
6C - NOT USED
6D - NOT USED
6E - EXTEND THE TELESCOPE
6F - RETRACT THE TELESCOPE
6G - RAISE THE MAIN ARM
6H - LOWER THE MAIN ARM
6I - TURN THE TURN TABLE TO THE LEFT
6J - TURN THE TURN TABLE TO THE RIGHT
6K - TILT BASKET/JIB ARM UP
6L - TILT BASKET/JIB ARM DOWN
DIMENSIONS
- A
10,060 mm
- A1
7,360 mm
- B
2,800 mm
C1
C
- C
2,525 mm
- C1
3,035 mm
- D
2,480 mm
- E
440 mm
- F
370 mm
- G
395 mm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 220 TJ+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Manitou 220 TJ+

  • Page 1 220 TJ+ BASIC INSTRUCTION SHEET No. 52585519EN (2018/12/01) THIS ALL-TERRAIN AERIAL WORK PLATFORM IS DESIGNED TO OPERATE ON NATURAL OR UNDEVELOPED LAND, OR CONSTRUCTION SITES. IMPORTANT This document is a short recap on how to operate an aerial work platform and should in no way be substituted for the manual required by Directive 2006/45/EC, which should be read and understood by the operator beforehand and stored in the basket of the aerial work platform.
  • Page 2 IMPORTANT We draw the operators' attention to the risks associated with using the aerial work platform, in particular: - risk of loss of control. - risk of loss of lateral stability of the aerial work platform. - it is MANDATORY to wear a safety helmet and a safety harness when using the platform. PLATFORM WORKING AREA TURN TABLE ROTATION BLOCK ELECTRICAL HAZARD...
