Digital communication

6.1

RS-232 communication

Digital Bronkhorst® instruments can be monitored and operated via RS-232 using the free FlowWare software tools for
Windows. These tools provide a graphical interface to the
The FlowWare toolkit provides functionality for monitoring and operating digital instruments (FlowSuite, FlowPlot),
selection of the active fluid and configuration of the fieldbus connection (if applicable). For instruments that support the
definition and use of multiple fluids FlowTune™ can be used to store fluid definitions in the instrument and select the
active fluid.
Digital instrument parameters are made accessible by FlowDDE, a Dynamic Data Exchange server (DDE) that handles
communication between the instrument and (dedicated) client software in Windows (e.g. FlowPlot). FlowDDE can also be
used by other client applications, such as Microsoft Office or custom made software, built with third party development
software like LabVIEW or a SCADA platform.
The FlowWare tools and associated documentation can be downloaded from the product pages on the Bronkhorst website:
www.bronkhorst.com/products
·
If the power and signal connector is set for RS-485 communication, the instrument will not respond to an RS-232
master. In that case, use the
·
After configuring the required parameters, follow the same procedure to leave configuration mode and restore the
original communication settings (otherwise, configuration mode will remain enabled after the next power-up).
For more information about communication through the RS-232 interface, consult the
6.2

Fieldbus communication

Not all parameters described in this document are necessarily available with all digital interface types. For information
about parameter access and availability for Bronkhorst® instruments in a specific fieldbus network, consult the according
fieldbus manual.
6.3

Parameters

A summary of all digital parameters in this section can be found in the back of this manual.
This section describes the most commonly used parameters for digital operation of the ES-FLOW™. Descriptions are
grouped by category in tables as shown below:
Type
[type]
In this manual, parameter names are printed in italics (reverted to normal where embedded in italics, like in this tip).
Type
Unsigned char 1 byte unsigned integer (0...255)
Unsigned int 2 byte unsigned integer, MSB first (0...65535)
Unsigned long 4 byte unsigned integer, MSB first (0...4294967295)
Float 4 byte floating point, IEEE 32-bit single precision, MSB first
Unsigned char [x] x byte text string
Access
R Parameter value can be read
W B Parameter value can be written
Parameter is secured and only accepts values if parameter Init Reset is set to 'unlocked' first
9.17.153E
multifunctional switch
Access Range
B
RW [x]...[y]
Instruction Manual ES-FLOW™ 1xxC
Bronkhorst®
ProPar protocol, for monitoring and editing parameter values.
to enter configuration mode and enable RS-232 communication.
FlowDDE FLOW-BUS
[DDE par] [Pro]/[Par]
RS-232 manual.
Modbus
[address]/[register]
