Counter New Setpoint
Type
Unsigned int
New (safe) setpoint when a counter limit is reached until reset. Range 0...32000 represents 0...100% setpoint.
Default value: 0
Reset Counter Enable
Type
Unsigned char
Available reset methods. The value is a bitwise summation of the enabled reset methods; convert the value to binary to see
which methods are enabled.
Default value: 7 (bits/methods 0, 1 and 2 enabled)
The following methods are supported:
Bit Value
0 1
1 2
2 4
3 8
6.3.4

Network configuration

Changes made to the network settings will not be restored by a factory reset.
Default configuration
Network configuration is done ex factory as ordered. The table below shows the supported configurations for the available
interface protocols (default settings are printed in bold):
Protocol
Address
Baud Rate
Parity
Network configuration for Ethernet based fieldbus types is done automatically via the Ethernet protocol.
Communication via fieldbus connector (RS-485)
Use the following parameters to configure the instrument for communication through the fieldbus connector (5-pin M12):
Fieldbus1 Address
Type
Unsigned char
9.17.153E
Access Range
RW 0...32000
Access Range
RW 0...15
Description
By hardware switch (if present)
Externally (obsolete)
By parameter Reset
Automatically (e.g. when counter value is reset)
ProPar FLOW-BUS
(RS-232) (RS-485)
3 3...125
9600
187500
19200
400000
38400
57600
115200
230400
460800
0 0
Access Range
B
RW 0...255
Instruction Manual ES-FLOW™ 1xxC
Bronkhorst®
FlowDDE FLOW-BUS
127 104/6
FlowDDE FLOW-BUS
157 104/9
Modbus PROFIBUS DP
(RTU/ASCII)
1...247 0...126
9600
(autodetect)
19200 9600
38400 19200
56000 45450
57600 93750
115200 187500
128000 500000
256000 1500000
3000000
6000000
12000000
0, 1, 2 2
FlowDDE FLOW-BUS
199 125/10
Modbus
0x0D06/3335
Modbus
0x0D09/3338
CANopen DeviceNet™
1...127 0...63
10000
125000
20000
250000
50000
500000
125000
250000
500000
800000
1000000
0 0
Modbus
0x0FAA/4011
