ADJ 32 HEX PANEL IP User Manual page 28

D M X T R A I T S
6CH 8CH 10CH 11CH 16CH 48CH 57CH 96CH
9
10
CHANNEL
11 52
12 53
13 54
14 55
10 15 56
11 16 57
DMX
FUNCTION
VALUES
Auto Programs (continued)
111 - 126 Flow 3
127 - 143 Flow 4
144 - 160 Flow 5
161 - 176 Flow 6
177 - 193 Flow 7
194 - 210 Flow 8
211 - 226 Flow 9
227 - 255 No Function
000 - 255 Auto Program Speed, slow to fast
Auto Program Fade, slow to fast
000 - 255
Dimmer Mode
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 255 Default to unit setting
LED Refresh Rate
000 - 015 Default to unit setting
016 - 030 900 Hz
031 - 045 1000 Hz
046 - 060 1100 Hz
061 - 075 1200 Hz
076 - 090 1300 Hz
091 - 105 1400 Hz
106 - 120 1500 Hz
121 - 135 2500 Hz
136 - 150 4000 Hz
151 - 165 5000 Hz
166 - 180 10,000 Hz
181 - 195 15,000 Hz
196 - 210 20,000 Hz
211 - 225 25,000 Hz
226 - 255 Off
Dim Curves
000 - 020 No Function
021 - 045 Linear
046 - 070 Square
071 - 095 Inv. Square
096 - 120 S-Curve
121 - 255 No Function
28
