ADJ 32 HEX PANEL IP User Manual page 26

D M X T R A I T S
6CH 8CH 10CH 11CH 16CH 48CH 57CH 96CH
CHANNEL
19 19
20 20
21 21
22 22
23 23
24 24
25 25
26 26
27 27
28 28
29 29
30 30
31 31
32 32
33 33
34 34
35 35
36 36
37 37
38 38
CONTINUED ON NEXT PAGE
DMX
FUNCTION
VALUES
UV Fine Zone 3, 0-100%
36 000 - 255
Red Zone 4, 0-100%
37 000 - 255
Red Fine Zone 4, 0-100%
38 000 - 255
Green Zone 4, 0-100%
39 000 - 255
40 000 - 255 Green Fine Zone 4, 0-100%
Blue Zone 4, 0-100%
41 000 - 255
Blue Fine Zone 4, 0-100%
42 000 - 255
White Zone 4, 0-100%
43 000 - 255
White Fine Zone 4, 0-100%
44 000 - 255
45 000 - 255 Amber Zone 4, 0-100%
Amber Fine Zone 4, 0-100%
46 000 - 255
UV Zone 4, 0-100%
47 000 - 255
UV Fine Zone 4, 0-100%
48 000 - 255
Red Zone 5, 0-100%
49 000 - 255
50 000 - 255 Red Fine Zone 5, 0-100%
Green Zone 5, 0-100%
51 000 - 255
Green Fine Zone 5, 0-100%
52 000 - 255
Blue Zone 5, 0-100%
53 000 - 255
Blue Fine Zone 5, 0-100%
54 000 - 255
55 000 - 255 White Zone 5, 0-100%
White Fine Zone 5, 0-100%
56 000 - 255
Amber Zone 5, 0-100%
57 000 - 255
Amber Fine Zone 5, 0-100%
58 000 - 255
UV Zone 5, 0-100%
59 000 - 255
60 000 - 255 UV Fine Zone 5, 0-100%
Red Zone 6, 0-100%
61 000 - 255
Red Fine Zone 6, 0-100%
62 000 - 255
Green Zone 6, 0-100%
63 000 - 255
Green Fine Zone 6, 0-100%
64 000 - 255
65 000 - 255 Blue Zone 6, 0-100%
Blue Fine Zone 6, 0-100%
66 000 - 255
White Zone 6, 0-100%
67 000 - 255
White Fine Zone 6, 0-100%
68 000 - 255
Amber Zone 6, 0-100%
69 000 - 255
Amber Fine Zone 6, 0-100%
70 000 - 255
UV Zone 6, 0-100%
71 000 - 255
UV Fine Zone 6, 0-100%
72 000 - 255
Red Zone 7, 0-100%
73 000 - 255
Red Fine Zone 7, 0-100%
74 000 - 255
Green Zone 7, 0-100%
75 000 - 255
26
