- Page 1 BG-PSC6X2-4K 6X2 4K 18Gbps UHD HDMI/USB-C/DP/VGA & Audio Conference Room Presentation Switcher/Scaler User Manual...
- Page 2 BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com...
-
Page 3: Table Of Contents
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL TABLE OF CONTENTS Statement Safety Precaution Introduction Features Packing List Technical Specifications Operation Controls and Functions Remote Control Description IR TX/RX Guidelines RS-232 Pin Assignment RS232 and Telnet Commands Application Example Tech Support Warranty Mission Statement Copyright ·... -
Page 4: Statement
● This product does not contain parts that can be maintained or repaired by users. Damage caused by dismantling the product without authorization from BZBGEAR is not covered under the warranty policy. ● Installation and use of this product must strictly comply with local electrical safety standards. -
Page 5: Introduction
PRODUCT MANUAL Introduction The BG-PSC6X2-4K is a 4K 18Gbps presentation scaler and switcher that supports 6 inputs including 3 HDMI inputs, 1 DisplayPort, 1 USB-C, and 1 VGA, with 2 HDMI mirrored outputs. Utilizing a built-in scaler chip, the video can be scaled to various aspect ratios and resolutions from 1024x768 up to 3840x 2160 @ 60Hz. -
Page 6: Technical Specifications
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL Technical Specifications General Bandwidth: 18Gbps Video Input Connectors: 3x HDMI Type A, 1x VGA, 1x USB-C, 1x DP Video Output Connectors: 2x HDMI Type A Audio Input Connectors: 1x 3.5mm stereo jack Audio Output Connectors: 1x 3.5mm stereo jack, 1x RCA (SPDIF) -
Page 7: Operation Controls And Functions
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL Operation Controls and Functions Front Panel 1. LCD display: It shows the status of input-to-output selection, EDID info, and the other information. 2. Power button: Press to power on the unit. 3. Mute button: Press to mute the HDMI outputs, L/R, & Coaxial audio outputs. - Page 8 BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL Rear Panel 18. TCP/IP port: RJ45 connector, for TCP/IP control. 19. RS232 port: DB9 female connector, to control the unit from a PC or control processor. 20. Coaxial audio output: Output coaxial audio which always follows HDMI outputs.
-
Page 9: Remote Control Description
● Embed: Audio on HDMI outputs is from L/R Analogue audio input (3.5mm Jack) Format: Video output resolution selection. The BG-PSC6X2-4K includes a built-in video scaler. Press the required resolution button on remote control to change the HDMI output video resolution MIC control: ●... -
Page 10: Ir Tx/Rx Guidelines
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL IR TX/RX Guidelines IR Emitter: Plug in the IR emitter to emit all IR command signals received from the IR receiver from the other end to control the devices corresponding to the IR signals. IR Receiver: Plug in the IR receiver to receiver all IR command signals from the IR remote controls of the corresponding devices. -
Page 11: Rs-232 Pin Assignment
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL RS-232 Pin Assignment The connection method is as follows: Baud Rate: 57600 bps Data Bit: 8-bit Parity: None Stop Bit: 1-bit Flow Control: None BG-PSC6X2-4K Remote Control Console Assignment Assignment · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 12: Rs232 And Telnet Commands
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL RS232 and Telnet Commands Command Action Print Help Information HELP Print Help Information STATUS Print System Status And Port Status Power On, System Run On Normal State POFF Power Off, System Run On Power Save State IR ON/OFF Set System IR Control On Or Off... - Page 13 BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL Command Action zz=12: DVI 1280x1024@60Hz, Audio None zz=13: DVI 1920x1080@60Hz, Audio None zz=14: DVI 1920x1200@60Hz, Audio None zz=15: User EDID 1 zz=16: User EDID 2 zz=17: GUI Download EDID zz=18: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM zz=19: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY...
-
Page 14: Application Example
BZBGEAR BG-PSC6X2-4K PRODUCT MANUAL Application Example · · Address: 830 National Drive #140, Sacramento, CA 95834, USA Tel: +1(888)499-9906 Email: support@bzbgear.com... -
Page 15: Tech Support
1.888.499.9906 support@bzbgear.com bzbgear.com Warranty BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended two-year warranty is available for our cameras upon registration for a total of five years. For complete warranty information, please visit bzbgear.com/warranty. For questions, please call 1.888.499.9906 or email support@bzbgear.com. -
Page 16: Copyright
PRODUCT MANUAL Copyright All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change...
