SSV Works RZ34-Q5A3 Installation Instructions Manual page 8

PANELS AND DASH DISASSEMBLY (ALL MODELS)
A. Remove all seats by releasing the handle behind each seat,
push forward slightly while lifting up.
PANELS AND DASH DISASSEMBLY (RZR3)
C. Remove hood by turning locking pins and lifting up.
E. Disconnect all harness connectors attached to the center dash panel.
A
B. Disconect the negative battery cable from the battery.
C
D. Remove center dash by unscrewing the (2) T-40 Torx screws and push center
dash forward to unclip.
E
F. Un-pin and pull to remove the passenger side safely handle.
D
B
D
F
