Installation reference

The following modules provide reference information for the Nortel
Ethernet Routing Switches.
Navigation
•
"Power specifications" (page 100)

RJ-45 connector pin assignments

The following section outlines the connector pin assignments for the RJ-45
connectors in the Nortel Ethernet Routing Switch 5500 Series switches.

Nortel Ethernet Routing Switch 5510 and 5530

The following table outlines the RJ-45 connector pin assignments in the
Nortel Ethernet Routing Switch 5510, 5530, and 5600 Series non-PoE
switches.
Connector
Copyright © 2008–2009 Nortel Networks
Pin Nu Signal for 10/1
mber
00Base-T MDI
configuration
1 Output transmit
data + (TX+)
2 Output transmit
data - (TX-)
3 Input receive data
+ (RX+)
6 Input receive data
+ (RX+)
4, 5, 7,
Not used
8
Pin Nu Signal for
mber
1GBase-T MDI
configuration
1
TP0+
2 TP0-

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
97
Signal for 10/10
0Base-T MDI-X
configuration
Input receive data
+ (RX+)
Input receive data -
(RX-)
Output transmit
data + (TX+)
Output transmit
data + (TX+)
Not used
Signal for
1GBase-T MDI-X
configuration
TP1+
TP1-
