Avaya Solution & Interoperability Test Lab
Configuring the Nortel 5520-24T-PWR Switch Supporting
Power over Ethernet with Avaya Communication Manager
and Avaya IP Telephones – Issue 1.0
These Application Notes describe the configuration of the Nortel 5520-24T-PWR switch and
Avaya 1600/4600/9600 Series IP Telephones registered to Avaya Communication Manager
and Avaya one-X Quick Edition IP Telephones and G10 PSTN Gateway.
JPA; Reviewed:
SPOC 8/6/2007
Abstract
Solution & Interoperability Test Lab Application Notes
©2007 Avaya Inc. All Rights Reserved.
1 of 8
Nortel5520PoE.doc
Advertisement
Related Manuals for Nortel 5520-24T-PWR
Summary of Contents for Nortel 5520-24T-PWR
- Page 1 Avaya IP Telephones – Issue 1.0 Abstract These Application Notes describe the configuration of the Nortel 5520-24T-PWR switch and Avaya 1600/4600/9600 Series IP Telephones registered to Avaya Communication Manager and Avaya one-X Quick Edition IP Telephones and G10 PSTN Gateway.
- Page 2 Powered Devices (PDs), such as PoE-enabled IP telephones. The Nortel 5520-24T-PWR switch provides 24 ports with PoE. The Avaya product configurations addressed by these Application Notes are shown in Figure 1. The following Avaya powered devices were covered: • Avaya one-X DeskPhone Edition IP Telephones : 9610, 9620, 9630 (with and without SBM24), 9640, 9650 •...
- Page 3 Figure 1: Network Configuration JPA; Reviewed: Solution & Interoperability Test Lab Application Notes 3 of 8 SPOC 8/6/2007 ©2007 Avaya Inc. All Rights Reserved. Nortel5520PoE.doc...
-
Page 4: Equipment And Software Validated
2. Equipment and Software Validated The following equipment and software were used for the configuration provided: Equipment Version Avaya G350 Media Gateway with Avaya Avaya Communication Manger 4.0 S8300B Media Server (R014x.00.0.730.5) Avaya one-X Deskphone Edition 9610 IP Telephone Avaya one-X Deskphone Edition 9620 IP... - Page 5 Nortel switch. Consult the Nortel configuration manual [2] for additional configuration details. The default configuration on the Nortel switch is sufficient to enable the Avaya IP Telephones to receive Power over Ethernet, as long as PoE is enabled on the port.
-
Page 6: Verification Steps
Quick Edition G10 PSTN gateway Table 1: Power Measurements * The Avaya one-X Value Edition 1603 IP Telephone with PoE Splitter is a Class 2 Powered Device. It was observed that the Nortel 5520-24T-PWR was not able to properly detect its class. -
Page 7: Additional References
7. Conclusion These Application Notes described configuration of the Nortel 5520-24T-PWR switch to power Avaya IP Telephones, and the Avaya one-X Quick Edition G10 PSTN Gateway. The Nortel 5520-24T-PWR switch was able to power all devices tested. 8. Additional References The Avaya product documentation is available at http://support.avaya.com. - Page 8 Application Notes. Please e-mail any questions or comments pertaining to these Application Notes along with the full title name and filename, located in the lower right corner, directly to the Avaya Solution & Interoperability Test Lab at interoplabnotes@list.avaya.com...
