Procedure Steps
Step
1
2
3

Setting non-base units

The following procedure describes the steps to set the units as non-base
switches.
Procedure Steps
Step
1

Setting non-base units using the UI button

This procedure describes the steps necessary to set a non-base unit using
the UI button.
Procedure Steps
Step
1
2
3
Copyright © 2008–2009 Nortel Networks
Action
Press and hold the UI button for three seconds.
The unit is now in configuration mode. The color and status of
the Status LED turns to blinking green.
Press the UI button once.
The Base LED is illuminated and the Up and Down LEDs are off
to indicate that the button press was recognized.
Press and hold the UI button for three seconds to confirm the
command.
The Status LED returns to a steady green state to confirm
command acceptance. If the command is rejected, the Status
LED moves to a blinking amber state.
Action
Set the Unit Select switch set to the left to designate them as
non-base units.
Action
Press and hold the UI button for three seconds.
The unit is now in configuration mode. The color and status of
the Status LED turns to blinking green.
Press the UI button twice.
The Base LED will turn off and the Up and Down LEDs are
turned off.
Press and hold the UI button for three seconds to confirm the
commands.

ERS 5000 Series Installation

NN47200-300 04.03
13 April 2009
Stack configuration 93
--End--
--End--
